Storage Rack Assembly & Mounting
7
Assembling Upper and Lower
Rack
Align the tabs in the upper rack with notch-
es in lower rack. Slide upper rack forward
until the hooks on the lower rack engages
the bottom flange of the upper rack. You
will hear an audible click when the locks
engage.
Tab of
Upper
Rack
Notch of
Lower
Rack
Upper
Rack
Lower
Rack
Mounting Storage Rack to Wall
• Do not mount over 5 feet from the floor.
• Do not attach screws to drywall only.
Make sure screws are attached to a
stud.
• Do not sit or hang on storage rack.
• Do not exceed maximum weight limit of
40 pounds.
1. Choose a location that is indoors and
not exposed to rain. For best perform-
ance and easy access, position the
storage rack so the center of the
vacuum inlet port is no more that five
feet from floor and no more than
eighteen feet from an electrical outlet.
5 Feet
Maximum
Vacuum Inlet
Port
Floor
