Radio Shack PLDVD188 - Manual

ANTI-THEFT FLIP DOWN DETACHABLE PANEL
CAR DVD VIDEO DIGITAL PLAYER
AM/FM-STEREO DIGITAL PLL TUNING RADIO
WITH INFRARED REMOTE CONTROLLER
INSTRUCTION MANUAL
Fully Compatible To All Types
Of Discs Such As DVD, VCD,
SUPER VCD, MP3, CD.
SPECIFICATION SPECIFICATION
GENERAL SPECIFICATIONS
Power Requirement...............................14.4V DC(10.8 to 15.6 allow)
Current Consumption.................................................Less than 2.0A
Maximun Power output....................................................240WATTS
Line output....................................................RMS 35W x 4 @ 4 ohm
Dimensions(w x h x d)............................................182 x 53 x 158mm
DVD DECK SPECIFICATIONS
Format...........................................DVD-Video Disc (2 Layer, 2 side)
Compact Disc
Video System...................................................Standard NTSC/PAL
Audio System..........................................................................MP3
Loading System......................................................... Auto Loading
Mounting Angle................................................................0 to +/-30
VIDEO SPECIFICATIONS
Video System..................................4:3 Letter Box and 4:3 Pan Scan
Video Output level.................................................1.0Vp-p 75 ohms
Horizontal Resolution................................................................500
Video Input Terminal......................................0.5 to 2.0Vp-p 75 ohms
AUDIO SPECIFICATIONS
Maximum Output.......................................................2Vrms(+/-3dB)
Frequency Response....................................................20 to 20KHz
S/N Ratio(A-vtd)......................................................................85dB
Separation..............................................................................80dB
RADIO SPECIFICATIONS
FM SECTION
Frequency range.................................................87.5MHz - 107.9MHz
Usable sensitivity......................................................................3uV
I.F Frequency.....................................................................10.7MHz
AM SECTION
Frequency...........................................................530KHz - 1710KHz
PLDVD188
www.pyleaudio.com
1
OPEN
+
LOC
-
SEL
ST
TRK
DVD/SVCD/VCD/CD/MP3 PLAYER
TOP RDM RPT 2 INT 3 4
POP
CLAS
ROCK
TITLE CHP
CLK 5 6 APS
PRG
CH
RPT INT LOC
DIGITAL DTS LOUD RDM
DOLBY
D I G I T A L
MU BND
DSP MD
IR
D
COMPACT
IGITAL AUDIO
D
COMPACT
IGITAL VIDEO
4 x 35 W
VIDEO
VIDEO
+
ENTER
UP
DN
LOC OSD
AUDIO
ST
TITLE/PBC
A/P
SUBTITLE
9
REPEAT
5 6
1 2
STOP PLAY
VOL-
VOL+
DSP CLK
ANGLE
0
MUTE
+10
7 8
3 4
PAUSE MENU
BAND
/PREV. F.BWD
/NEXT F.FWD
MODE SEL
POWER
