Main Unit
103
8
❖ ❖ ❖ ❖ Continuous copying count:
1 – 99 copies
❖ ❖ ❖ ❖ Copy paper capacity:
Type 1:
• Tray 1: 250 sheets (80 g/m
2 , 20 lb)
• Bypass: 100 sheets (80 g/m 2 , 20 lb)
Type 2:
• Tray 1, 2: 250 sheets (80 g/m
2 , 20 lb)
• Bypass: 100 sheets (80 g/m 2 , 20 lb)
❖ ❖ ❖ ❖ Power consumption:
*1 Main unit with the optional fax unit, printer/scanner unit, and paper tray unit.
❖ ❖ ❖ ❖ Dimensions (W ЧЧЧЧ D ЧЧЧЧ H up to exposure glass):
Type 1: 550
Ч 568 Ч 420 mm, 21.65" Ч 22.36" Ч 16.54"
Type 2: 550
Ч 568 Ч 558 mm, 21.65" Ч 22.36" Ч 21.97"
❖ ❖ ❖ ❖ Noise Emission *1 :
• Sound power level
• Sound pressure level *2
*1 The above measurements made in accordance with ISO 7779 are actual values.
*2 Measured at the position of the operator.
*3 The Complete system consists of a main unit with full options installed.
❖ ❖ ❖ ❖ Weight:
Type 1: 35 kg (78 lb) or less
Type 2: 44 kg (96 lb) or less
Note
❒ Specifications are subject to change without notice.
Main unit only Complete system *1
Warm up Less than 1,280 W Less than 1,280 W
Stand-by About 110 W About 130 W
During printing About 440 W About 450 W
Maximum Less than 1,280 W Less than 1,280 W
Main unit only Complete system *3
Stand-by 40 dB (A) 40 dB (A)
During printing 59 dB (A) 66 dB (A)
Main unit only Complete system *3
Stand-by 26 dB (A) 26 dB (A)
During printing 46 dB (A) 55 dB (A)
