12 13
OPERATION
Fig. 6
Hex Key Storage
Insert hex key into storage area when not in use. It is located
on the right front of your saw as shown in figure 6.
WARNING:
Do not insert saw blade or hex key into air vents.
They could come in contact with electrically live
internal parts, and cause electrical shock resulting
in serious injury.
WARNING:
To avoid serious personal injury, do not use saw
without chip shield properly in place.
General Cutting
See Figure 7.
Rest the front of the saw base on the workpiece and align
cutting edge of the blade with the line on your workpiece.
Make sure the power cord is out of your way and not in
the line of cut. Start your saw and move it forward on the
work surface. Apply downward pressure to keep the saw
steady and only enough forward pressure to keep the
blade cutting.
Do Not Force The Saw
Forcing your saw may overheat the motor and break saw
blades.
Fig. 7
HEX KEY
TO INCREASE
ORBITAL SETTING
TO DECREASE
ORBITAL SETTING
