5.3 Data Port Specifications
5.3.1 Serial Ports
5.3.1.1 Copper Ports
Parameter
Specifications
Notes
Baud Rate
300 bps – 230 kbps
Connector
DB9 or RJ45
Isolation
2.5 kV
RMS 1-minute
Table 9: Copper Port Specification
5.3.1.2 Fiber Optic Ports
Parameter
Specifications
Mode
Multimode
Connector
ST
Typical Dist. (km)
5
Optical Wavelength (nm)
820
Cable Size
Core/Cladding (um)
50/125
62.5/125
Table 10: Fiber Optic Port Specification
NOTES:
1.
Maximum segment length is greatly dependent on factors such as fiber quality, and
number of patches and splices. Please consult RuggedCom sales associates when
determining maximum segment distances.
