Notes:
1 Standard on on/off boilers (H4); Optional on all others
2 Standard on Models 302B and 402B; Optional on Models 502B-902B
3 Optional on Models 302B and 402B; Standard on Models 502B-902B
4 Standard on 992B; Optional on 1262B-2342B
5 Not available on Model 992B; Standard on Models 1262B-2342B ⅷ ⅷ = Standard ⅜ ⅜ = Optional
HEA
T EXCHANGER
Water Heaters (Type WH)
HD101-HD401 302B-902B 992B-2342B
Boilers (Type H)
HD101-HD401 302B-902B 992B-2342B
ASME, National Board Registered, 160 PSI H Stamp ⅷ ⅷ ⅷ N/A N/A N/A
HLW Stamp N/A N/A N/A ⅷ ⅷ ⅷ
Heat Exchanger Tubes Copper ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Cupro Nickel ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Headers Bronze ⅜ ⅜ ⅜ ⅷ ⅷ ⅷ
Cast Iron ⅷ ⅷ ⅷ ⅜ ⅜ ⅜
Pressure Relief Valve 30, 45, 60, 75, 125 & 150 PSI Available ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Temperature & Pressure Gauge ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Pump – 120V, Single-Phase ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
OPERA
TING CONTROLS
120V Power Supply With 120V/24V Transformer ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Pump Time Delay Single Phase ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Diagnostic Display Central 16-Event Memory N/A ⅷ ⅷ N/A ⅷ ⅷ
Temperature Controller B-20: On/Off, Mechanical ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
B-28: On/Off, Digital ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
B-6: 2-Stage, Mechanical ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
B-26–B-27: 2-Stage, Digital ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
B-21–B-23: 4-Stage, Digital ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
B-24: 2-Stage, Raytemp (Digital) N/A ⅜ ⅜ N/A ⅜ ⅜
B-25: 4-Stage, Raytemp (Digital) ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Y-200 Series, Digital ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
SAFETIES
Hot Surface Ignition System 3-try ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
1-try N/A ⅜ ⅜ N/A ⅜ ⅜
High Gas Pressure Switch ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Low Gas Pressure Switch ⅜ ⅜ ⅷ ⅜ ⅜ ⅷ
Blocked Vent and Air Pressure Switches ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
High Limit Switch Manual Reset, Fixed ⅷ N/A N/A ⅷ N/A N/A
Manual Reset, Adjustable ⅜ ⅷ ⅷ ⅜ ⅷ ⅷ
Automatic Reset, Adjustable ⅜ (1) ⅜ ⅜ ⅜ ⅜
Low Water Cut-Off, 24V With manual reset and test button ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Flow Switch ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
GAS TRAIN
Firing Mode On/Off (H4, WH1) ⅜ (2) ⅜ ⅷ (2) ⅜
2-Stage (H3, WH3) ⅷ (3) ⅜ ⅜ (3) ⅜
3-Stage (H8, WH8) N/A N/A (4) N/A N/A (4)
4-Stage (H9, WH9) N/A N/A (5) N/A N/A (5)
4” WC Supply Pressure Natural Gas Only ⅷ ⅜ (6) ⅷ ⅜ (6)
AIR
TruSeal Direct Vent System ⅷ ⅜ ⅜ ⅷ ⅜ ⅜
Air Filter, Room Air ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Air Filter, Ducted Outside Air ⅷ ⅜ ⅜ ⅷ ⅜ ⅜
OTHER
Efficiency 84% (Category I) ⅷ ⅷ ⅷ N/A N/A N/A
(98% available; See Specialty Models) 85% (Category I) N/A N/A N/A ⅷ ⅷ ⅷ
87% (Category II) N/A ⅜ ⅜ N/A N/A N/A
Combustible Floor Rated ⅷ ⅷ ⅷ ⅷ ⅷ ⅷ
Alarm System ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Vent Terminal Outdoor and Through-the-Wall ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
Right-Hand Water Connections ⅜ ⅜ ⅜ ⅜ ⅜ ⅜
CSD-1/GE GAP Control System N/A (7) ⅜ N/A (7) ⅜
Low NOx Compliance Meets all current requirements ⅷ ⅷ (8) ⅷ ⅷ (8)
Cold Water Start Cold water protection systems N/A ⅜ ⅜ N/A ⅜ ⅜
Cold Water Run Cold water protection systems N/A ⅜ ⅜ N/A ⅜ ⅜
6 Option but not available on Model 2002B
7 Not applicable for Models 302B and 402B; Optional for Models 502B-902B
8 Standard on Models 992B-2002B; Models 2072B and 2342B
require site testing and have different emissions requirements
(Consult factory)
Raypak, Inc. • 2151 Eastman Ave., Oxnard, CA 93030 • phone: (805) 278-5300 • fax: (800) 872-9725 • www.raypak.com
Cat. No. 1100.12C Effective 11-15-09 Replaces: 07-01-09
