1. Things to Check When Unpacking


The M38C29T-ADF package consists of the following products. When unpacking your package, check to see that all of these
components are included.
If you find any item missing or faulty, or any suggestion, contact your local distributor.

Table 1.1 Package components

Item

M38C29T-ADF temporary target board
M38C29T-ADF User’s Manual (this manual)


2. Outline

The M38C29T-ADF is a temporary target board used to develop software with a compact emulator M38000T2-CPE or PC4701

emulator system. It supplies to the M38C29RLFS MCU the minimum required signals needed to operate the emulator MCU,

including power supply voltage, clock signals and reset signals. Use it when the user system is not ready.


3. Specifications


Table 3.1 lists the specifications of the M38C29T-ADF.

Table 3.1 Specifications

Applicable MCU

M38C29RLFS

Clock

4.0MHz oscillator mounted (oscillator circuit board OSC-2 used)
32.768kHz (can be disconnected by SW1)

Vcc Supplied

separately*

Vss Supplied

separately

RESET

- Reset circuit mounted (power-on reset and reset switch)
- Connects the reset output of an emulation pod
Width 90mm

External dimensions

Depth 115mm

Others

Universal part prepared


* Power cannot be supplied from the emulator (e.g. M38000T2-CPE). A separate power supply is needed.

(2/8)
