Ramsey Electronics MR6 User Manual
Page 16
MR6
• 16
MODEL ROCKET TRACKING TRANSMITTER
Quick Reference Page Guide
Introduction to the MR6 ................. 4
How it works .................................. 4
SMT soldering instructions .............5
Parts list ......................................... 7
Parts Layout diagram ..................... 8
Schematic diagram ........................ 9
MR6 Assembly instructions ......... 10
Hook-up configurations .................13
Troubleshooting ............................13
Ramsey kit warranty .....................15
Price: $5.00
Ramsey Publication No. MMR6
Assembly and Instruction manual for:
RAMSEY MODEL NO. MR6 MODEL ROCKET
TRACKING TRANSMITTER KIT
RAMSEY ELECTRONICS, INC.
590 Fishers Station Drive
Victor, New York 14564
Phone (585) 924-4560
Fax (585) 924-4555
www.ramseyelectronics.com
REQUIRED TOOLS
•
Soldering Iron Ramsey WLC100
•
Thin Rosin Core Solder Ramsey RTS12
•
Needle Nose Pliers Ramsey MPP4 or RTS05
•
Small Diagonal Cutters Ramsey RTS04
ADDITIONAL SUGGESTED ITEMS
•
Holder for PC Board/Parts Ramsey HH3
•
Desoldering Braid Ramsey RTS08
•
Digital Multimeter Ramsey M133
