28 RV53i & RV53e Operation and Installation Manual
Additional Clearances
Local codes supersede these clearances.
•
Avoid termination locations near a dryer vent.
•
Avoid termination locations near commercial cooking exhaust.
60"
V
V
(1.52 m) between
Rinnai terminals
at different levels
12"
12"
36"
INSIDE
CORNER
V V
(0.91 m) to ventilated
or unventilated soffit
or eve vent; or to a
deck or porch
(0.30 m ) to an
inside corner
(0.30 m) between
Rinnai terminals at
same level
24"
V
(0.61 m) to wall or parapet
(0.30 m) between
Rinnai terminals at
same level
12"
V V
(1.52 m) vertically
between Rinnai terminals
V
60"
V
Vent terminal (represents
concentric vent terminal)
2"
36"
12"
IN SID E
C O R NER
(0.91 m) to ventilated
or unventilated soffit
or eve vent; or to a
deck or porch
50 mm)
between Rinnai
terminals at
same level
RV53i RV53
e
