8. Correspondence of Connectors J1 and J2
Table 2 lists the correspondence of M3T-DIRECT80S and connectors J1, J2.
Table 2 Correspondence of M3T-DIRECT80S and connectors J1, J2
(NC: not connected)
DIRECT80S
pin No.
Connector
pin No.
1
J1-1
2
J1-2
3
J1-3
4
J1-4
5
J1-5
6
J1-6
7
J1-7
8
J1-8
9
J1-9
10
J1-10
11
J1-11
12
J1-12
13
J1-13
14
J1-14
15
J1-15
16
17
J1-16
18
J1-17
19
J1-18
20
J1-19
21
J1-20
22
J1-21
23
J1-22
24
J1-23
NC
J1-24
25
J1-26
26
J1-27
27
J1-28
28
J1-29
29
J1-30
30
J1-31
31
J1-32
32
J1-33
NC J1-34
NC J1-35
NC J1-36
NC J1-37
NC J1-38
NC J1-39
NC J1-40
NC J1-41
NC J1-42
73
J1-43
74
J1-44
75
J1-45
76
J1-46
77
J1-47
78
J1-48
79
J1-49
80
J1-50 J1-25
65
J2-1
66
J2-2
67
J2-3
68
J2-4
69
J2-5
70
J2-6
71
J2-7
72
J2-8
NC J2-9
NC J2-10
NC J2-11
NC J2-12
NC J2-13
NC J2-14
NC J2-15
NC
NC J2-16
33
J2-17
34
J2-18
35
J2-19
36
J2-20
37
J2-21
38
J2-22
39
J2-23
40
J2-24
NC J2-26
41
J2-27
42
J2-28
43
J2-29
44
J2-30
45
J2-31
46
J2-32
47
J2-33
48
J2-34
49
J2-35
50
J2-36
51
J2-37
52
J2-38
53
J2-39
54
J2-40
55
J2-41
56
J2-42
57
J2-43
58
J2-44
59
J2-45
60
J2-46
61
J2-47
62
J2-48
63
J2-49
64
J2-50 J2-25
9. Recommended Procedure for Soldering M3T-DIRECT80S
(4/4)
(1) Fix the soldering position
• Use a soldering iron having a large contact surface.
• Move the soldering iron in parallel with each surface
(with a feeling of causing the solder to flow).
• Pressing the semicircular through holes hard may cause them to get
crushed, so be careful.
• Make certain that no solder bridges are present.
Effect tack soldering.
(3) Solder
(2) Apply the flux
• Apply flux to the semicircular through holes on the four sides.
Flux
Connector
pin No.
Connector
pin No.
Connector
pin No.
DIRECT80S
pin No.
DIRECT80S
pin No.
DIRECT80S
pin No.
