6. Memory Map
Figures 6.1 and 6.2 show the MCU and the PROM programmer memory maps (programming areas).
Figure 6.1 Memory map (M37272E8SP)
00000
16
013FF
16
03C00
16
03BFF
16
08000
16
07FFF
16
0FFFF
16
1FFFF
16
10000
16
0FFFF
16
08000
16
07FFF
16
03C00
16
03BFF
16
013FF
16
01400
16
00000
16
MCU
(M37272E8SP)
PROM programmer
(M5M27C101 mode)
Internal
ROM area
(32K bytes)
Programming
area
OSD ROM
256 kinds
OSD ROM
256 kinds
01400
16
