Precautions, J1 connectors and pins of nqpack, Caution – Renesas Converter Board for M30102 M30102T-PTC User Manual
Page 4: Important, Caution to be taken for this product
( 4 / 4 )
8. J1 Connectors and Pins of NQPACK
Table 2 lists the connections of the J1 connectors and the pins of the NQPACK.
Table 2 Connections of the J1 connectors and the pins of the NQPACK
CAUTION
Caution to Be Taken for This Product:
• When connecting the M30102T-PTC, be sure to use the included YQ-GUIDE's.
7. Precautions
Connector No.
NQPACK
Connector No.
NQPACK
J1-1
-
J1-26
-
J1-2
43
J1-27
19
J1-3
44
J1-28
20
J1-4
45
J1-29
21
J1-5
46
J1-30
22
J1-6
47
J1-31
23
J1-7
48
J1-32
24
J1-8
1
J1-33
25
J1-9
2
J1-34
26
J1-10
3
J1-35
27
J1-11
4
J1-36
28
J1-12
5
J1-37
29
J1-13
6
J1-38
30
J1-14
7
J1-39
31
J1-15
8
J1-40
32
J1-16
9
J1-41
33
J1-17
10
J1-42
34
J1-18
11
J1-43
35
J1-19
12
J1-44
36
J1-20
13
J1-45
37
J1-21
14
J1-46
38
J1-22
15
J1-47
39
J1-23
16
J1-48
40
J1-24
17
J1-49
41
J1-25
18
J1-50
42
IMPORTANT
Notes for This Product:
• We cannot accept any request for repair.
• For purchasing the NQPACK048SD, YQPACK048SD and HQPACK048SD, contact
the following:
Daimaru Kogyo Ltd.
http://www.daimarukogyo.co.jp/
Tokyo Eletech Corporation http://www.tetc.co.jp/e_tet.htm
• For inquiries about the product or the contents of this manual, contact your local
distributor.
Renesas Tools Homepage http://www.renesas.com/en/tools
