Ricoh Aficio SP C311N/SP C312DN
System Specifications
System Specifications
Main Unit SP C311N – Part #406466
SP C312DN – Part #406467
Configuration Desktop
Technology Laser beam scanning, color laser
electrophotographic printing with
monocomponent toner development,
4-drum tandem method
Resolution 600 x 600 dpi (default),
1200 x 600 dpi, 2400 x 600 dpi
Printing Speed B/W: 26 ppm (Letter),
FC: 26 ppm (Letter)
First Print Speed 13.5 sec. or less
Auto Duplex SP C312DN only
Standard Paper Capacity 500 sheets
Bypass Tray 100 sheets
Optional Paper Feed Unit 500 sheets (one Paper Feed Unit
may be added)
Maximum Paper Capacity Up to 1,100 sheets
Output Capacity 150 sheets (face down)
Acceptable Paper Sizes Standard Paper Trays: Letter (8.5"
x 11") to Legal (8.5" x 14"),
A4 (8.27" x 11.69"), B5 (6.93"
x 9.84");
Bypass Tray: 3.56" x 5.85" to 8.5"
x 14", A4 (8.27" x 11.69"),
A5 (5.8" x 8.3"), B5 (6.93" x 9.84"),
Banners (up to 8.5" x 35")
Optional Paper Feed Unit: Letter
(8.5" x 11"), A4 (8.27" x 11.69")
Acceptable Paper Weights Standard Tray and Optional Paper
Feed Unit: 16 – 28 lb. Bond
(60 – 105 g/m
2 );
Bypass Tray: 16 – 53 lb. Bond /
110 lb. Index (60 – 200 g/m 2 );
Duplex Unit (SP C312DN only):
16 – 28 lb. Bond (60 – 105 g/m
2 )
Acceptable Paper Types Standard Tray and Optional Paper
Feed Unit: Plain Paper, Recycled
Paper, Pre-punched Paper, Thin
Paper, Color Paper, Pre-printed
Paper, Letterhead
Bypass Tray: Plain Paper, Recycled
Paper, Application Paper, Envelope,
Glossy, Thick Paper, Label, Thin
Paper, Cardstock
Dimensions (WxHxD) 15.8" x 15.2" x 18.9"
(400 mm x 387 mm x 480 mm)
Weight 61.73 lb. (28.0 kg)
Warm-Up Time 30 sec. or less
Power Source 120V, 60Hz
Power Consumption Maximum: 1300W or less
Energy Saver: 15W or less
Safety Regulations UL60950-1, FCC Part 15 Class B
device, Energy Star Color Printers –
Tier 1 (SP C312DN only)
Controller Specifications
CPU 400 MHz
Printer Languages PCL 5c/6, PostScript 3 emulation
Fonts PCL/PS3: HP80 fonts
Memory (RAM) 128 MB standard/640 MB maximum
Standard Interfaces USB 2.0, 10/100Base-TX Ethernet,
PictBridge (SP C312DN only)
Optional Interface IEEE 802.11b/g
Network Protocols TCP/IP, IPX/SPX, AppleTalk
Operating Systems Windows 2000/XP/Server 2003/
Vista/Server 2008; Mac OS X
v.10.2+; Novell NetWare 4.x+;
Citrix MetaFrame; UNIX (using
Ricoh UNIX filter)
Drivers PCL 5c/6: Windows 2000/XP/
Server 2003/Server 2008/Vista;
PostScript 3: Windows 2000/XP/
Server 2003/Server 2008/Vista,
Mac OS X Native (v 10.2.8 – 10.5)
Controller Options
256 MB Memory Unit Type F Part #003310MIU
512 MB Memory Unit Type F Part #003311MIU
IEEE 802.11b/g SX-2500CG Part #100118FNG
Wireless Adaptor
Optional Accessories
Paper Feed Unit Part #406019
Type TK1010 Paper Size: Letter (8.5" x 11"),
A4 (8.3" x 11.7");
Paper Weight: 16 - 28 lb. Bond
(60 g/m 2 )
Capacity: 500 sheets
Software Utilities
SmartDeviceMonitor
Web Image Monitor
Consumables and Yields
Toner Type SP C310A Black 2,500 prints* Part #406344
Toner Type SP C310A Cyan 2,500 prints* Part #406345
Toner Type SP C310A Magenta 2,500 prints* Part #406346
Toner Type SP C310A Yellow 2,500 prints* Part #406347
Toner Type SP C310HA Black 6,500 prints* Part #406475
Toner Type SP C310HA Cyan 6,000 prints* Part #406476
Toner Type SP C310HA Magenta 6,000 prints* Part #406477
Toner Type SP C310HA Yellow 6,000 prints* Part #406478
Maintenance Kit** 90,000 prints Part #406081
Type SP C310
Intermediate Transfer Unit 90,000 prints Part #406067
Type SP C310
Waste Toner Bottle 55,000 prints Part #406066
Type SP C310
*Declared yield values are in accordance with ISO/IEC 19798.
Actual yields may vary based on images printed and other factors.
Ships with toner kits (2,500 prints for all toners); all other consumables
ship at full yield.
**Maintenance Kit consists of the Fusing Unit and Transfer Roller.
Specifications subject to change without notice.
Warranty
The Ricoh Aficio SP C311N/SP C312DN is under warranty against
defects for a period of one year from the date of purchase.
Consumables are under warranty for a period of 90 days from
the date of purchase or until depleted, which ever comes first.
Please refer to warranty document shipped with the product
for more details.
