Wireless Router RNX-N400LX User Manual
7. Select Specify an IP address and type in values as following example.
IP Address: 192.168.1.1, any IP address within 192.168.1.1 to
192.168.1.253 is good to connect the Wireless LAN Access
Point.
IP Subnet Mask: 255.255.255.0
8. Click OK to complete the IP parameters setting.
2.2 Connecting RNX-N400LX
You have the option to use either the Setup Wizard program in the CD to help you set up
RNX-N400LX or you can use the web browser to setup. Please connect RNX-N400LX
with your computer and modem to start the setup process. (Instruction in 1.7 Hardware
Setup)
2.21 Connecting using Setup Wizard:
1. Setup wizard program will provide you with a very preliminary setup for your
router. When inserting your RNX-N400LX’s CD into the CD-ROM/DVD-ROM,
you will see a popup window like below:
2. Click Setup Wizard to begin setup process. You will see a process icon
appear:
3. Immediately follow the process icon, process will appear:
17
