Ricoh Aficio

SP C420DN

System Specifications

R2732

Printed in U.S.A. on recycled paper because Ricoh cares.

www.ricoh-usa.com

Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh

and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. Windows

and Windows

98/2000/NT4.0/XP/2003/Vista are registered trademarks of Microsoft Corporation. Macintosh

is a registered

trademark of Apple Computer, Inc. PCL is a registered trademark of Hewlett-Packard Company. PictBridge is a registered trademark of Canon, Inc. All other trademarks are the property of their respective owners.
Print speed may be affected by network, application or PC performance. Specifications and external appearances are subject to change without notice. Products are shown with optional features.

Engine Specifications

Configuration

Desktop

Technology

Laser-beam scanning, Electro-
photographic, Dual component
toner, 4 tandem drum method

Resolution

600 x 600 dpi (default); 1200 x
600 dpi; 1200 x 1200 dpi

Printing Speed

31 pages-per-minute in full-color
and B&W

First Print Speed

Color: 15 seconds; B&W:
10 seconds

Dimensions (WxDxH)

17.6" x 23.2" x 19.2"
(446 mm x 589.5 mm x 487 mm)

Weight

110 lb. or less (50 kg)

Warm-Up Time

Less than 30 seconds

Power Source

120V, 60Hz

Maximum Power

990W or less

Consumption

Energy Saver Mode

6W or less

Maximum Paper Capacity Up to 2,300 sheets
Standard Paper Capacity

550 sheets

Bypass Tray

100 sheets

Optional Paper Feed Unit 550 sheets (up to three paper

feed units can be added)

Automatic Duplex

Standard (prints at nearly
100% simplex speed through
standard tray)

Output Capacity

500 sheets, face down

Paper Sizes

Letter (8.5" x 11"), A4 (8.3" x

(All Sources)

11.7"), A5 (210 x 297 mm), EXE
(7.25" x 10.5"), B5 (6.9" x 9.8"),
Legal (8.5" x 14")
Custom Sizes: Standard Paper Tray
and Optional Paper Feed Units:
(width 3.9" – 8.5", length 5.8" –
14") Bypass Tray (width 2.8" –
8.5", length 5.5" – 35.4")

Paper Weight

14 lb. – 57 lb. Bond / 120 lb.

(All Sources)

Index (52 – 216 g/m

)

Duplexing: 16 lb. – 43 lb. Bond /
90 lb. Index (60 – 163 g/m

)

Acceptable Paper Types

Thick paper/Card stock (Up to 57

(All Sources)

lb. / 120 lb. Index / 216 g/m

Plain Paper/Recycled Paper, Laser
Printer Qualified Transparencies,
Envelopes (Com 10, Monarch, C6,
C5, DL)

Safety Regulations

UL UL60950, FCC Part15 Class B
device, Energy Star Tier 2
compliant

Controller Specifications

CPU

PMC-Sierra RM7935-835L
800 MHz

Printer Languages

Adobe PostScript3, PCL 5c, PCL 6,
Ricoh RPCS, PDF Direct,
PictBridge

™

(optional)

Fonts

136 PostScript 3 fonts, 45 PCL
fonts, 13 International fonts

Memory (RAM)

256 MB RAM standard; 512 MB
RAM maximum

Hard Disk Drive

60 GB optional (40 GB reserved
for file storage)

Standard Interfaces

10/100Base-TX Ethernet, USB 2.0,
USB Host I/F

Optional Interfaces

IEEE 1284, IEEE 802.11a/g
Wireless LAN, Bluetooth Wireless,
Gigabit Ethernet

Network Protocols

Simultaneous auto-sensing/auto
switching TCP/IP, Novell IPX/SPX,
AppleTalk

Operating Systems

Windows 2000/XP/Server
2003/Vista; NetWare v 3.12, 3.2,
4.1, 4.11, 5.0, 5.1, 6, 6.5;
Macintosh OS 8.6 – 9.2x, OS X
10.1, 10.2, 10.3 or later; UNIX
(using Ricoh UNIX filter Phase 11)
Sun Solaris, HP-UX, Red Hat Linux,
SCO Open Server, IBM AIX (for
UNIX support, visit www.ricoh-
usa.com/downloads); SAP R/3
3.x or later

Drivers

RPCS/PCL 5c/PCL 6: Windows
2000/XP/Server2003/Vista
XPS: Windows Vista (via
download only)
PS: Windows 2000/XP/Server
2003/Vista; Mac OS 8.6 – 9.2x,
OS X 10.1 or later; UNIX: Sun
Solaris, HP-UX, Red Hat Linux,
SCO OpenServer, IBM AIX

Print Utilities

SmartDeviceMonitor for Admin,
Web SmartDeviceMonitor,
Web Image Monitor,
DeskTopBinder V2 Lite, Printer
Utility for Mac, Agfa Font
Manager 2000, DeskTopBinder
Professional (optional)

Controller Options

60 GB Hard Disk Drive

Type 420

Part #402999

IEEE 1284 Interface

Type A

Part #411699

IEEE 802.11a/g Interface

Type L

Part #403000

Bluetooth Interface

Type 3245

Part #412866

Gigabit Ethernet

Type A

Part #402547

Data Storage Card

Type A

Part #402627

VM Card

Type H

Part #403054

Device Customization: VM Card for Java-based device SDK
option
Camera Direct Print Card

Type D

Part #402996

(SD Card)
Enables direct printing from a PictBridge

™

-enabled digital

camera, without a PC.

Memory Options

128 MB Memory Unit

Type G

Part #402965

256 MB Memory Unit

Type G

Part #414046

144-pin DIMM SD-RAM (PC133 Compliant); Maximum 512 MB

Security Options

DataOverwriteSecurity

Type K

Part #402998

System (DOSS) (optional)
Overwrites latent data on the system’s hard drive after print
jobs.

HDD Encryption Unit

Type C

Part #402997

(optional)
Encrypts data stored in the device’s NVRAM and on the Hard
Disk Drive.

Other Security Features

SNMP v3 Authentication and Data Encryption (password/
address book encryption); Print Data Encryption via Internet
Printing Protocol (IPP); PDF Direct Print Password Protection;
Locked (Secure) Print; 500 User Account Codes; User
Authentication; WPA (Wi-Fi Protect Access Support)

Paper Handling Accessories

Paper Feed Unit Type 4000: Part #420165
Paper Size

Standard: Letter (8.5" x 11"), A4
(8.3" x 11.7"), A5 (210 x 297
mm), EXE (7.25" x 10.5"), B5
(6.9" x 9.8"), Legal (8.5" x 14")
Custom: (width 3.9" – 8.5",
length 5.8" – 14"

Free Paper Weights

14 – 57 lb. Bond /120 lb. Index
(52 – 216 g/m

)

Capacity

550 sheets; up to 3 units may
be added

Printer Stand FAC29: Part #402390

Consumables

HY Black Toner Cartridge Part #888308

Yield: 15,000 pages*

HY Yellow Toner Cartridge Part #888309

Yield: 15,000 pages*

HY Magenta Toner Cartridge Part #888310

Yield: 15,000 pages*

HY Cyan Toner Cartridge

Part #888311
Yield: 15,000 pages*

Black Toner Cartridge

Part #888276
Yield: 5,000 pages*

Yellow Toner Cartridge

Part #888277
Yield: 5,000 pages*

Magenta Toner Cartridge Part #888278

Yield: 5,000 pages*

Cyan Toner Cartridge

Part #888279
Yield: 5,000 pages*

Photoconductor Unit Black

Part #402319
Yield: 50,000 pages

Photoconductor Unit Color

Part #402320
Yield: 50,000 pages

Waste Toner Bottle

Part #402324
Yield: 50,000 pages

Intermediate Transfer Unit Part #402323

Yield: 100,000 pages

Maintenance Kit

Part #402593

(Type C411)

Yield: 100,000 pages

Includes Fusing Unit, Transfer Roller, Paper Feed Roller.

Paper Feed Roller for

Part #403066

3rd Paper Feed Unit

Yield: 100,000 pages

*Declared yield value in accordance with ISO/IEC 19798.
The SP C420DN ships with starter toner cartridges that
yield 3,000 pages; all other consumables ship at full yield.
For maximum performance and yield, we recommend
using genuine Ricoh parts and supplies.
Specifications subject to change without notice.
