Ricoh Aficio

MP C6000/C7500

System Specifications

Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh

and the Ricoh Logo are registered trademarks of Ricoh Company, Ltd. Windows

and Windows

95/98/ Me/NT4.0/2000/XP/Vista are registered trademarks of Microsoft Corporation. Macintosh

, Mac

OS and

AppleTalk

are registered trademarks of Apple Computer, Inc. Adobe

and PostScript

are registered trademarks of Adobe Systems, Inc. PCL

is a registered trademark of Hewlett-Packard Company. RPCS

™

is a trade-

mark of Ricoh Company, Ltd. All other trademarks are the property of their respective owners. Print speed may be affected by network, application or PC performance. Specifications and external appearances are
subject to change without notice. Products are shown with optional features.

R2597

Printed in U.S.A. on recycled paper because Ricoh cares.

www.ricoh-usa.com

Copier Specifications

Configuration

Console

Scanning Element

Flatbed with moving 3-line CCD
array image-scanning

Toner

Chemical toner

System Memory

320GB (160GB x 2)

Document Feeder

Standard 100-Sheet ARDF

Copy Resolution

600 x 600 dpi

Color

256 Levels

Image Density

Manual & Automatic

Quantity Indicator

1 - 9,999

Original Type

Sheet/Book/Object

Original Size

Up to 11" x 17"

Warm-Up Time

MP C6000 <90 sec.
MP C7500 <75 sec.

First-Copy Out Time

MP C6000 5.7/7.5 sec. (BW/FC)
MP C7500 4.9/6.4 sec. (BW/FC)

Speed

MP C6000 60/55 cpm (BW/FC)
MP C7500 75/70 cpm (BW/FC)

Standard Paper

1st Tray 1,100 x 2

Capacity

550 sheets x 2nd & 3rd Trays,
100-Sheet Bypass Tray
7,400 sheet std. max capacity

Paper Size

5.5" x 8.5" to 12" x 18"

Paper Weight

14 lb. Bond - 80 lb. Cover (std. Trays)
17 lb. Bond - 90 lb. Index (Duplex)
14 lb. Bond - 110 lb. Cover (Bypass)

Magnification

7 reduction and 5 enlargement

Zoom

25% to 400% in 1% increments

Power Source

C6000/120 V/20A/60 Hz
C7500/208-240V/20A/60Hz

Dimensions (WxDxH)

29.5" x 33.5" x 43.1" (excluding ARDF)

Weight

< 656.9 lb.

Copier Features

Auto Paper Selection, Auto Reduce/Enlarge, Auto Start,
Auto Tray Switching, Auto Image Density, Auto Reduce and
Enlarge, Duplex, User Codes, Stapling, Color Erase/Convert,
Electronic Sort, Image Rotation, Rotate Sorting, Series Copy,
Doc Server, User Tools, Job Presets, Book/Series/Combine,
Insert Cover/SlipSheet, Chaptering, Tabs, OHP, Color/Image
Creation, Sample Copy, Energy Saver, Image Adjustment,
Multiple Security Options

Printer Specifications

CPU

Intel Pentium - M 1.4GHz

RAM

1,536MB (std./max)

HDD

320GB (160GB x 2)

Standard Interfaces

Ethernet (100BaseTX10 Base-T),
USB2.0

Optional Interfaces

IEEE1284, Wireless LAN
(IEEE802.11a/g) Bluetooth,
Ethernet 1000 Base-T

Network Protocol

TCP/IP, IPX/SPX, SMB, Apple Talk

Operating Systems

WIndows: 2000/XP/Vista/Server
2003. Netware; 3.12, 3.2, 4.1,
4.11, 5.0, 5.1, 6, 6.5. Unix, Sun
Solaris, HP-UX, SCO OpenServer,
RedHat Linux, IBM AIX. MAC: OS
8.6 - 9.2x, OS X 10.1 or later

PDL

RPCS, PCL5c, PCL6,
Adobe PS3 (optional)

Print Resolution

600 dpi

Fonts for PCL

35 Intellifonts, 10 TrueType Fonts,
International Fonts: 13 Intellifonts

Fonts for PostScript

136 Adobe PostScript Type1 Fonts

Scanner Specifications

Scanning Resolution

Up to 600 dpi

Scan Area

Up to 11" x 17"

Scan Speed

81/69 ipm (BW/FC)

Compression

BW/Binary - TIFF MH/MR/MMR Full
Color/Grayscale JPEG (5 levels)

Standard Interfaces

10BaseT/100BaseTX, Wireless LAN

Scanner Features

BW/OCR, BW/FC Photo, BW/FC Text,
Auto Color, Auto Density, Image
Rotation, Mixed Size, SADF Batch

Scan-To Destinations

Scan-to-Email
Scan-to-Folder
Scan-to-URL
TWAIN Scanning

Scan-To-Email
Authentication

SMTP, POP before SMTP

Resolution

Default 200 dpi to 600 dpi

Max. 2,000 addresses

Addresses in HDD

Max. 500 addresses

Addresses in HDD

LDAP

Yes, up to five LDAP Servers

File Type

Single/Multi-Page PDF, Single/ Multi-
Page TIFF, High Comp. PDF

File Size

128 - 102,400 KB*

*If file exceeds size, It will be divided into multiple e-mails.

Scan-To-Folder
Protocol Support

SMB, FTP, NCP

Security

Client folder log-in, Encryption of
name and password during trans.

Resolution

Default 200 dpi to 600 dpi

Client Folder

Max. 2,000

Addresses in HDD

Group Addresses

Max. 100 destinations

Size Restriction

None

File Type

Single/Multi-Page PDF, Single/ Multi-
Page TIFF, High Comp. PDF

Document Server Specifications (Standard)

HDD Capacity

191.8GB

Max. Stored Documents 3,000
Max. Pages per Document 2,000
Max. Stored Pages

15,000

Fax Specifications (Optional)

Circuit

PSTN, PBX

Compatibility

ITU-T (CCITT) G3,
Additional G3 optional

Resolution

200 x 100/200 dpi (400 dpi w/opt.
SAF memory)

Compression Method

MH, MR, MMR, JBIG

Scanning Speed

0.5 sec

Modem Speed

33.6 Kbps - 2,400 bps

Transmission Speed

G3: Approx 2 sec.

Memory Backup

1 Hour

Quick/Speed Dials

2,000 numbers

Group Dials

100 groups (500 per group)

Energy Saver

Standard

Accessories

RT4000 DLT/LCT
Paper Capacity

2,000 Sheets

Paper Size

up to 12" x 18"

Paper Weight

14 lb. - 110 lb. Cover

Size

38.1" x 28" x 29.3"

Weight

192 lbs.

RT43/LCT
Paper Capacity

4,000 Sheets

Paper Size

8.5" x 11"

Paper Weight

14 lb. - 34 lb. Bond

Size

12" x 18" x 26"

Weight

44 lbs

CS391 9-Bin Mailbox
Number of Bins

Stack Capacity of Bins

100 Sheets

Paper Size

5.5" x 8.5" - 11" x 17"

Paper Weight

14 lb. - 34 lb. Bond

Size

21" x 24" x 26"

Weight

33 lbs.

Z-Fold Unit
Paper Size

8.5" x 11" and 11" x 17"

Paper Weight

17 lb. - 20 lb. Bond

Size

7" x 24" x 38"

Weight

121 lbs.

2 Source Cover Interposer
Paper Size

5.5" x 8.5" - 12" x 18"

Paper Weight

17 lb. Bond - 110 lb. Index

Size

28" x 29" x 50"

Weight

99 lbs.

SR5000 100-Sheet Staple Finisher**
Capacity (Proof Tray)

500 Sheets (8.5" x 11" or smaller)
250 Sheets (8.5" x 14" or larger)

Paper Size

5.5" x 8.5" - 12" x 18"

Capacity (Shift Tray)

8.5" x 11" - 3,000 Sheets
8.5" x 14" - 11" x 17"- 1,500
Sheets
12" x 18" - 1,000 Sheets

Paper Weight

14 lb. Bond - 110 lb. Cover

Staple

8.5" x 11" - 100 Pages
8.5" x 14" - 11" x 17" - 50 Pages

Size

31" x 29" x 39"

Weight

165 lbs.

**SR5000 must include Finisher Adapter Type C.

SR4010 50-Sheet Staple Finisher
Capacity (Proof Tray)

250 Sheets (8.5" x 11" or smaller)
50 Sheets (8.5" x 14" or larger)

Paper Size

5.5" x 8.5" - 12" x 18"

Capacity (Shift Tray)

8.5" x 11" - 3,000 Sheets
8.5" x 14" - 11" x 17" - 1,500
Sheets

Paper Weight

14 lb. Bond- 110 lb. Cover

Staple

8.5" x 11" - 50 Pages
8.5" x 14" - 11" x 17" - 30 Pages

Size

26" x 24" x 38"

Weight

119 lbs.

SR4020 Booklet Maker
Capacity (Proof Tray)

250 Sheets (8.5" x 11" or smaller)
50 Sheets (8.5" x 14" or larger)

Paper Size

5.5" x 8.5" - 12" x 18"

Capacity (Shift Tray)

8.5" x 11" - 2,000 Sheets
8.5" x 14" - 11" x 17" - 1,000
Sheets

Paper Weight

14 lb. Bond - 110 lb. Cover

Staple

8.5" x 11" - 50 Pages
8.5" x 14" - 11" x 17" - 30 Pages

Saddle Stitch Staple***

8.5" x 11" - 12" x 18" - 15 Pages

Size

26" x 24" x 38"

Weight

139 lbs.

***Paper weight for saddle stitch stapling is 28 lb. Bond max.

Additional Accessories

Punch Unit for SR5000
Punch Unit for SR4010/4020
Jogger Option for 4010/4020
Legal Tray for RT43 LCT Type 1075
11" x 17" Tray Type 2105
Copy Connector Kit Type 3260
Tab Sheet Unit Type 3260
File Format Converter Type E
HDD Overwrite Security Kit Type H
Copy Data Security Kit Type F
HDD Encryption Unit Type A
Adobe PostScript3 Type C7500
IEEE802.11a/g Type J
IEEE1284 Type A
Bluetooth Interface Unit Type 3245
Browser Unit Type D
Java VM Card Type F
G3 Interface Kit Type C7500
Key Counter Bracket Type 1027
Reader Key Card Bracket Type B
Key Card I/F Unit Type A
Gigabit Ethernet Type B
