10
RMB-1512 Twelve Channel Power Amplifier
Troubleshooting
Most difficulties in audio systems are the result of poor or wrong
connections, or improper control settings. If you encounter problems,
isolate the area of the difficulty, check the control settings, determine
the cause of the fault and make the necessary changes. If you are
unable to get sound from the RMB-1512, refer to the suggestions for
the following conditions:
Standby Power Indicator Is Not Lit
No main power to the RMB-1512. Check AC power connections at
the amplifier and the AC outlet. Check the front panel power switch.
Make sure that it is set to the ON position. If using signal sensing auto
power-on, make sure that a signal is present at the inputs. If using 12V
trigger power-on, make sure that a trigger signal is present at rear
panel 12V TRIG IN connector.
No Sound
If the amp is getting AC power, but is producing no sound, check the
PROTECTION INDICATORS on the front panel. If lit, see below. If
not, check all of your connections and control settings on associated
components.
Protection Indicator Is Lit
The front panel PROTECTION INDICATORS light when the RMB-1512
protection circuits have shut off the amplifier. Typically, this occurs only
when the ventilation openings are blocked,when there is faulty speaker
wiring, or after a period of extreme use. Turn off the system and wait
for the amp to cool. Then push the front panel power switch in and
out to reset the protection devices. If the problem is not corrected or
reoccurs, there is a problem with the system or the amplifier itself.
Specifications
Continuous Power Output 100 watts/channel
(20-20k Hz, <0.03% THD, 8 ohms)
Total Harmonic Distortion (20Hz -- 22Hz, 8 ohms)
< 0.03%
Intermodulation Distortion (60Hz:7kHz, 4:1) < 0.03%
Damping Factor (20Hz-20kHz, 8ohms) 200
Input Impedance/Sensitivity 8.3 ohms/1.25 volts
Amplifier Gain 27.2db
Frequency Response (±1db) 10Hz - 40Khz
S/N Ratio (IHF A) 105 db
Crosstalk / Separation > 70 db
Speaker Impedance 4 ohms minimum
Auto Turn On level (with all inputs) 5mV input signal
Power Requirements USA: 120 volts, 60Hz
Europe: 230 volts, 50Hz
Power Consumption 660 watts
Idle: 84 watts
Standby: 10.8 watts
Dimensions (W x H x D) 431 x 144 x 449 mm
17 x 5.7 x 17.8 in
Weight (net) 10.9 kgs, 23.98 lbs
Panel Height 3U, 132,6 mm / 5.2 in
All specifications are accurate at the time of printing.
Rotel reserves the right to make improvements without notice.
