Ricoh Gig# Vision VGA Monochrome CCD Camera FV-G030B1 - Manual (Page 8)

8/38
FV-G030B1
User’s Guide Rev. 1.02
2.2.2 1/2 Partial Scanning
1 H = 21.1852 μs, 180.16662 Hz
2.2.3 1/4 Partial Scanning
1 H = 21.1852 μs, 360.33325 Hz
243H
Video out
Vertical blanking
262H
One vertical (1V)
19H 19H
Video output
3
6
8
3
6
9
1
2
7
1
2
8
FVAL
243H 19H 19H
LVAL
DVAL
104H
Video out
Vertical blanking
131H
One vertical (1V)
104H
27H 27H
Video output
2
9
9
3
0
0
1
9
7
1
9
8
FVAL
27H 27H
LVAL
DVAL
