Section 1 Configuration

CAUTION

Use an IC149-080-017-B5 socket (manufactured by

YAMAICHI ELECTRONICS Co., Ltd.) for the FP-80A package
IC socket on the user system.

Figure 1 shows the configuration of the HS3001ECH61H user system interface cable for the
FP-80A package.
