Control and layout for the monitor
Notice: some functions are work by remote control.
Blue screen when
no video signal
Control and layout for the remote control
Adjust Decrease
This multipurpose button serves
to decrease the selected
parameters, such as volume,
contrast etc.
Menu
Press to display MENU
with functions and setting
Adjust Increase
This multipurpose button
serves to increase the selected
parameters, such as volume,
contrast etc.
Remote Sensor
Remote control IR sensor
Power On / Off
Turn on/off the monitor Front A/V Input
Front audio video input
Front Audio Output
Front audio output
(headphones)
Power Cord
(Male)
4
Power On/Off
Turn On / Off the monitor
V1/V2
Select Video 1 or Video 2 Input
Volume
Adjust reduce headphone output
volume
Reduce
Menu
This button brings up the on-screen
menu for adjustment of a range of
monitor parameters such as,
vol, con, col, bri, tint. Etc
Preset
Picture preset by factory
Adjust Increase
This mu ltipurpose bu tton se rves to
adjust down to se lect me nu function
an d increase the se lected parame ters
su ch as co ntrast, color, brightness etc
Invert
To adjust the picture
up/down/left/right
Adjust Decrease
This multipurpose button serves to
adjust up to select menu function
and decrease the selected parameters
such as contrast, color, brightness etc.
Volume Increase
Adjust increase headphone output
volume
Mute
Press to Mute the sound, press again
to restore the previous volume level
When you use a wireless radio or portable telephone near
this unit, picture or sound interference may occur. Do not
use such devices near this unit.
MMI Input
Front audio video input
(Plug & Play for Ps2 or games)
