Page 1
Power
• Depress the power button on either the remote
control or the right side of the monitor to power
the EM1 on.
Switching Channels
• Using either the remote control or the buttons on
the right side of the monitor, switch the channels
up or down as desired.
Switching Inputs
• To select the auxiliary input (AV) or cable (TV,
CATV) input press the mode button on the remote
or on the left side of the monitor.
Volume Up/Down
Mode
Speakers
Power
Channel Up/Down
Remote Sensor Lens
1 EM1 Quick Reference Guide
Page 12
5 Using Auxiliary Sources
3 Installing Your EM1
Your EM1 has the capability to have one auxiliary source
plugged into it at a time. This may include DVD players,
closed circuit TV, camcorders, video game systems and
other NTSC (RCA type) inputs.
Plug in your V (video) L (left audio) and R (right audio)
RCA cables into the appropriate spot on the EM1 Tuner
module. Plug in your auxiliary source power supply (unless
the auxiliary is supplied with battery power).
Push the MODE button on your remote until AV is
displayed in the upper right corner of the monitor. Turn
power on to your input source. This should display video
and audio should come from the EM1’s speakers. For
operation of your auxiliary source please refer to it’s operation
manual.
Auxiliary
Input
tuner module
