Page 7
Section 1 Configuration
CAUTION
Use an IC149-KS-11113-0 socket (manufactured by
YAMAICHI ELECTRONICS Co., Ltd.) for the FP-100A
package IC socket on the user system.
Figure 1 shows the configuration of the HS3834ECF61H user system interface cable for the
FP-100A package.
Figure 1 HS3834ECF61H User System Interface Cable
1
