5
1. Emplacement des pieces 1. Situación de las piezas
Français Español
1. Garde avant
2. Poignée de démarrage
3. Capot du filtre à air
4. Bouton de starter
5. Poussoir de sécurité
6. Manette de daoite
7. Gâchette d’acéiérateur
8. Interruptear
9. Réservoir de carburant
10. Réservoirdhuik
11. Manette de gauche
12. Chaîne
13. Guide-Chaîne
14. Pompe d’amorçage
15. Protection anti-rebond
1. Protector delantero
2. Arrancador
3. Cubierta del filtro de aire
4. Botón dae estrangulador
5. Suguro del acelerador
6. Asa derecha
7. Palanea del acelerador
8. Interruptor
9. Tanque de combustible
10. Tanque de aceite
11. Asa izquierda
12. Cadena de la motosierre
13. Barraguia
14. Bomba cebadora
15. Protección de contragolpe
Français 2. Fiche technique
■ GZ400
Groupe moteur :
Cylindrée (cm 3 ) : ······································································································································40,1
Carburant : ········································································ Mélange (Essence/Huile moteur 2-temps : 50/1)
(Lors de l’utilisation de la véritable huile RedMax/ZENOAH)
Contenance du réservoir de carburant (cm 3 ) : ·························································································310
Huile de guide-chaîne et chaîne : ······································································Huile moteur SAE# 10W-30
Contenance du réservoir d’huile (cm
3 ) : ···································································································210
Carburateur : ·······························································································Type à membrane (ZAMA C1Q)
Allumage : ················································································································································CDI
Bougie : ····································································································································NGK CMR7H
Alimentation en huile :····································································································Pompe automatique
Puissance ··············································································································1,77kw/10,000min
-1 (rpm)
Vitesse maximum ···············································································································12,500min -1 (rpm)
Vitesse de ralenti··················································································································2,700min -1 (rpm)
Roue dentée (Nombre de dents x Pas) : ·························································································6T x 3/8"
Dimensions (Long. x Larg. x Haut.) (mm) :···········································································370 x 235 x 270
Poids à vide : Groupe moteur seulement (kg) :·························································································4,4
Tête de coupe :
Guide-chaîne
Type : - Taille (pouces (mm)) : ································································Extrémité à roue dentée - 18 (450)
Chaîne
Type : - Longueur des maillons (pouces (mm)) : - Largeur (pouces (mm)) :··········· 3/8 (9,53) - 0,050 (1,27)
Les caractéristiques peuvent être modifiées sans préavis.
Español 2. Especificaciohes
■ GZ400
Unidad de potencia:
Cilindrada (cm 3 ): ······································································································································40,1
Combustible:················································Mezcla (Gasolina: 50, Aceite para motores de dos tiempos: 1)
(al utilizar el aceite auténtico de RedMax/ZENOAH)
Capacidad del tanque de combustible (cm 3 ): ···························································································310
Aceite para la barra guía y cadena: ·······················································Aceite para motores SAE# 10W-30
Capacidad del tanque de aceite (cm
3 ): ····································································································210
Carburador: ······································································································Tipo diafragma (ZAMA C1Q)
Sistema de encendido: ····························································································································CDI
Bujía: ········································································································································NGK CMR7H
Sistema de alimentación de aceite: ·················································································Bomba automática
Potencia ·················································································································1,77kw/10,000min
-1 (rpm)
Máx. velocidad ···················································································································12,500min -1 (rpm)
Velocidad en ralentí ·············································································································2,700min -1 (rpm)
Rueda dentada (Dientes x Paso):····································································································6T x 3/8
″
Dimensiones (Lar x An x Al) (mm):·······················································································370 x 235 x 270
Peso seco : Sólo unidad de potencia (kg):································································································4,4
Cabezal cortante:
Barra guía
Tipo: - Dimensiones (pulg. (mm)):·····················································Extremo con rueda dentada - 18 (450)
Cadena de la motosierra
Tipo: - Paso (pulg. (mm)): - Calibre (pulg. (mm)): ····················································3/8 (9,53) - 0,050 (1,27)
Las especificaciones están sujetas a cambios y modificaciones sin previo aviso.
