ii
Contents
Section 1 Configuration ......................................................................................1
Section 2 Connection Procedures .......................................................................3
2.1 Connecting User System Interface Cable to Emulator Station ......................................... 3
2.2 Connecting User System Interface Cable to User System ................................................ 5
2.2.1
Installing IC Socket ............................................................................................. 5
2.2.2 Inserting Cable Head ........................................................................................... 6
2.2.3 Fastening Cable Head .......................................................................................... 7
2.2.4 Fastening Cable Body .......................................................................................... 9
2.3 Recommended Dimensions for User System Mount Pad ................................................. 10
2.4 Dimensions for User System Interface Cable Head.......................................................... 11
2.5 Resulting Dimensions after Connecting User System Interface Cable ............................. 12
Section 3 Installing the MCU to the User System.............................................13
Section 4 Verifying Operation...........................................................................15
Section 5 Notice ................................................................................................16
