RedMax HBZ2500 User Manual
Page 19
Key#
Part Number
Description
Q'ty
1
6811-11110
VOLUTE CASE
1
2
T4022-11300
VOLUTE COVER-A
1
3
1600-33130
SCREW
3
4
T4970-52001
SCREW TORX
12
5
6811-11130
GURG NET
1
6
6811-11160
STOPPER
1
7
T4970-51410
SCREW TORX
1
8
6811-11150
LEVER
1
9
6811-72200
SWITCH
1
10
T4022-11210
ENGINE COVER
1
11
4820-85510
SCREW TORX
2
12
T4960-53510
SCREW TORX
4
13
6811-12110
FAN
1
14
1650-43230
182301 NUT
1
15
6811-12220
WASHER
2
16
T4022-19110
LABEL, CAUTION
1
17
T4022-75610
LABEL, RECOIL
1
18
6811-51210
PIPE CT2-18
1
19
6811-51220
PIPE, END CT2-19
1
20
T4017-91130
SOCKET
1
21
HBN-100
FLAT NOZZLE SET
1
22
6811-51210
PIPE
1
23
6811-51230
FLAT NOZZLE
1
Fig.2 BLOWER GROUP HBZ2500
Key#
Part Number
Description
Q'ty
❲
19
❳
OPTION
