RedMax BACKPACK EBZ8000RH - Manual (Page 29)

29
EBZ8000/EBZ8000RH
Fig.2 ENGINE GROUP (S/N 40500101 and up)
Key# Part Number Description Q'ty
1 848H0012A1 CYLINDER 1
2 848H0012B1 GASKET, BASE 1
3 4820-12130 BOLT TORX 4
4 848H0012G0 PLATE, CYL 1
5 T4960-50810 SCREW TORX 2
6 848H0014A0 INSULATOR 1
7 8488152001 BOLT TORX 4
8 848H0014B2 GASKET, INSU 1
9 848H0014C1 GASKET, CARB 1
10 848H0012C0 COVER, TR-S 1
11 848H0012D0 COVER, TR-F 1
12 4820-72150 BOLT TORX 4
13 848H0012E1 GASKET TR 2
14 848H001510 MUFFLER ASSY 1
15 1421-15120 • ARRESTER 1
17 T4950-67031 BOLT TORX 2
18 T4950-61431 BOLT TORX 1
19 848H0015C0 GASKET, MUFFLER 1
20 848H002110 CRANKCASE COMP. 1
21 848H0021D1 GASKET, CASE 1
22 84889G4200 BEARING 2
23 8488AG2700 SEAL 1
24 8488AG4200 SEAL 1
25 04065-04218 SNAP RING 2
26 4820-21310 BOLT TORX 4
27 848H0021H0 COVER 1
28 4820-72150 BOLT TORX 1
29 8488164500 BOLT TORX 6
30 848H0041A1 PISTON 1
31 8488C50200 RING 2
32 8488BC4500 PIN 1
33 8488T31300 SNAP RING 2
34 84888C1600 BEARING 1
35 848873C000 WASHER 2
36 848H004201 CRANKSHAFT COMP. 1
37 848870G000 SHIM 1
38 1400-43230 NUT 1
39 1000-43240 KEY 1
40 848H0071A0 ROTOR 1
41 848H007120 COIL ASSY 1
42 T1108-72110 • CAP 1
43 T1108-72120 • SPRING 1
44 T1108-72130 • TUBE 1
45 5500-72130 • GROMMET 1
46 4820-72150 BOLT TORX 2
Key# Part Number Description Q'ty
47 T1108-71240 CORD COMP. 1
48 3699-91809 SPARKPLUG 1
49 848H007510 RECOIL ASSY 1
50 848H0075C0 • REEL 1
51 848H0075B0 • SPRING 1
52 848H0075M0 • WASHER 1
53 848H0075L0 • SPRING FRICTION 1
54 848H0075K0 • PLATE FRICTION 1
55 848H0075W0 • WASHER 1
56 4500-75150 • SCREW 1
57 8488S90000 • ROPE 1
58 848H0075J0 • KNOB 1
59 848H0075Z0 • KNOB CAP 1
60 848H007520 PULLEY ASSY 1
61 4820-32120 BOLT TORX 4
62 848H008100 CARBURETOR ASSY 1
63 4820-82310 BOLT TORX 2
64 848H008330 CUP ASSY 1
65 848H0083C0 • PLATE, CHOKE 1
66 848H0083D0 • LEVER 1
67 T1108-82190 • SCREW 1
68 848H008340 COVER ASSY 1
69 848H0083K1 • SCREEN 1
70 1491-82360 • SCREW 2
71 T4970-52510 SCREW TORX 3
72 848H0083M1 GASKET, CUP 1
73 4500-81910 COVER 1
