27
EBZ8000/EBZ8000RH
Fig.1 BLOWER GROUP (S/N 40500101 and up)
Key# Part Number Description Q'ty
1 848L5855A3 VOLUTE CASE 1
2 848L5855E1 PLATE(A) 1
3 848L5855F1 PLATE(B) 1
4 848L5855Z0 VOLUTE COVER 1
5 848L5855G0 BRACKET 2
6 2750-72230 CLAMP 1
7 T4970-52510 SCREW TORX 17
8 T4970-51410 SCREW TORX 6
9 848L5855C0 ELBOW 1
10 07000-12100 O-RING 1
11 T4960-57030 SCREW TORX 2
12 3310-53331 NUT 2
13 848L5855D3 COVER INRET 1
14 8488K40010 CLAMP 1
15 848L5855J0 CAP 1
16 848L585211 FAN COMP. 1
17 T4950-63031 BOLT TORX 4
18 848L5831A2 ENGINE COVER 1
19 T4970-52510 SCREW TORX 4
20 848L583513 FRAME COMP. 1
21 – • FRAME 1
22 3490-21121 • RING 2
23 848L583611 BAND ASSY 2
24 848L5836C1 CLIP 2
25 848L5835C2 PAD 1
26 3495-21320 CLIP 6
27 848L583521 NET COMP. 1
28 1480-74710 CLIP 4
29 2750-32510 DAMPER 1
30 2750-32520 WASHER 1
31 8488154000 BOLT TORX 1
32 T4960-51631 SCREW TORX 2
33 2750-32610 DAMPER 2
34 2750-32620 NUT (M6) 2
35 848L5883A2 BODY, CLEANER 1
36 848L5883U2 CASE, INNER 1
37 848L588322 COVER ASSY 1
38 – • COVER 1
39 T4012-82220 • COVER 1
40 T4970-52510 • SCREW TORX 2
41 848L5883J1 • KNOB BOLT 2
42 T4012-82311 ELEMENT 1
43 T4012-82321 ELEMENT 1
44 848L5883P1 HOSE 1
45 8488K40000 CLAMP 2
46 T4950-52030 BOLT TORX 4
Key# Part Number Description Q'ty
47 8488645000 NUT 4
48 848L588511 TANK ASSY 1
49 T1015-85202 • CAP ASSY 1
50 4500-85300 • • HOLDER ASSY 1
51 4500-85220 • • PACKING 1
52 5601-85260 • • FILTER 1
53 4820-85260 • • STOPPER 1
54 848L588530 • PIPE COMP. 1
55 3302-85400 • FILTER 1
56 1260-85460 • CLIP 1
57 T4960-51231 SCREW TORX 3
58 1950-86120 CLIP 1
60 2750-31911 LABEL, CAUTION 1
61 T4012-32610 LABEL, NET 1
62 848L5890R0 LABEL, EBZ8000 1
63 848L5890S0 LABEL 1
64 T4012-82280 LABEL 1
70 848L5865A1 HOSE 1
71 848L586510 SWIVEL JOINT 1
72 848L5865D0 PIPE, STRAIGHT 1
73 848L5865E0 PIPE, END 1
74 8488K40020 CLAMP 1
75 8488K40030 CLAMP 1
76 848L583620 BAND ASSY 1
80 8488U00020 TOOL-SET 1
81 3540-91120 • SPANNER 1
82 8488U10020 • SOCKET 1
90 848L5893A0 MANUAL 1
