J3

Pin

Circuit Net Name

Device

Pin

Pin

Circuit Net Name

Device Pin

1 IRQ0/TRIGa*

27

2 IRQ1/IO_6*

28

3 IRQ2/IO_7*

29

4 LCD_E

30

5 LCD_RS

31

6 AD_POT

32

7 P3_1

33

8 TMR1

34

9 IO_5

35

10 IO_4

36

11 IO_3

37

12 AD0

38

13 No

Connection

-

14 No

Connection

-

Table 9-3: J3

J4

Pin

Circuit Net Name

Device

Pin

Pin

Circuit Net Name

Device Pin

1 No

Connection

-

2 AD1

41

3 AD2

42

4 AD3

43

5 P4_2/VREF

44

6 IO_0

45

7 IO_2

46

8 IO_1

47

9 LCD_D7

48

10 LCD_D6

49

11 LCD_D5

50

12 LCD_D4

51

13 MO_UD

52

14 No

Connection

-

Table 9-4: J4

15
