Ricoh Aficio SP 3400N/SP 3410DN
Designed for Your Desktop and Your Budget
Choose from two compact models designed to meet
today’s space, workflow and purchasing requirements
while investing in a solution that will serve tomorrow’s
needs as your business grows. The RICOH
® Aficio ®
SP 3400N/SP 3410DN bring productive black & white
network laser printing to home offices and small
businesses at a low total cost of ownership.
Maximum Productivity, Minimal Effort
Fast, reliable and easy to use, bringing professional
printing capabilities to every user.
• Finish every job faster with efficient 30-ppm output speeds, and make every page
look its best with laser-sharp 1200 x 600 dpi maximum resolution.
• Process every file with ease. The 295MHz CPU and standard 64 MB RAM quickly
handle incoming data streams in popular PCL 6 or PostScript 3 emulation to keep
the pages flowing.
• Leverage the power of standard Ethernet networking. A USB 2.0 interface is also
standard to drive the unit through a single Windows PC or Mac.
• Save time and energy with a fast 20-second warm-up time and first print speeds
of just 8 seconds.
Versatile, Expandable Media Support
Support demanding workloads with a variety of
media requirements.
• Choose the Ricoh Aficio SP 3410DN with standard automatic duplexing for
productive two-sided printing, or the more economical Ricoh Aficio SP 3400N
for single-sided output.
• Print onto a wide range of media sizes up to 8.5” x 14” and paper weights up to
90 lb. Index. User-adjustable, front-loading paper trays enhance system flexibility.
• Speed envelope printing via the 50-Sheet Bypass Tray for in-house customer
invoicing and mailing applications.
• Expand paper capacity up to 550 sheets to handle longer jobs and growing
volumes with less interruption. The optional 250-Sheet Paper Feed Unit installs
beneath the standard 250-Sheet Tray to maintain a compact footprint.
Affordable and Virtually Maintenance Free
Compact and cost-effective, maximizing productivity
while helping to control printing costs.
• Invest with confidence. Aggressive hardware pricing, a robust feature set and
a high duty cycle deliver superior value and a low total cost of ownership.
• Choose the Standard Yield All-In-One (AIO) print cartridge (2,500 pages) to
minimize out-of-pocket supply expenses, or the High Yield AIO (5,000 pages)
to bring cost-per-page factors down even more.
• Simplify consumable replacement. Exchange the front-loading AIO print cartridge
in seconds in a quick, mess-free process.
• Use integrated Automatic Duplexing (Ricoh Aficio SP 3410DN) to save paper,
mailing costs and filing space.
Engine Specifications
Aficio SP 3400N Part # 406451
Aficio SP 3410DN Part # 406454
Configuration Desktop
Technology Laser beam scanning, electrophotographic printing
using dry mono-component toner development
Resolution 600 x 600 dpi, 1200 x 600 dpi equivalent
Print Speed 30 pages-per-minute (Letter)
First Print Speed 8 seconds or less
Warm-Up Time 20 seconds or less
Maximum Paper Size 8.5” x 14”
Standard Paper Supply 250-Sheet* Tray + 50-Sheet* Bypass Tray
Optional Paper Supply 250-Sheet* Paper Feed Unit
Maximum Paper Capacity 550 sheets
Output Capacity 125 sheets (face down)
Duplexing Manual: SP 3400N
Automatic: SP 3410DN (approx. 50% productivity)
Paper Sizes Paper Tray: 8.5” x 11” to 8.5” x 14”; A4, B5, A5,
A6, HLT, Executive, Foolscap, Folio;
Custom Size: 3.94” x 5.83” to 8.5” x 14.02”
Bypass Tray: 8.5” x 11” to 8.5” x 14”; A4, B5, A5,
A6, HLT, Executive, Foolscap, Folio;
Custom Size: 3.54” x 5.92” to 8.5” x 14.02”
Optional Paper Feed Unit: 8.5” x 11” to 8.5” x 14”;
A4, B5, A5, HLT
Paper Weights Standard & Bypass Tray:
14 - 43 lb. Bond/90 lb. Index (52 - 162 g/m 2 )
Optional Paper Feed Unit:
16 - 28 lb. Bond (60 - 105 g/m 2 )
When Duplexing:
16 - 28 lb. Bond (60 - 105 g/m 2 )
Paper Types Standard Tray: Plain Paper, Recycled Paper
Bypass Tray: Plain Paper, Recycled Paper,
Envelopes, Labels
Optional Paper Feed Unit: Plain Paper,
Recycled Paper
Dimensions (WxDxH) 14.5” x 15.4” x 10.3” (370 x 392 x 262 mm)
Weight SP 3400N: 25.6 lb. (11.6 kg) (includes AIO)
SP 3410DN: 27.6 lb. (12.5 kg) (includes AIO)
Power Requirements 120V, 60Hz
Power Consumption Maximum: 850W, Energy Saver: 5W
ENERGY STAR V. 1.2 compliant (SP 3410DN only)
Safety Regulations UL60950-1, FCC Class B
*Using 20 lb. Bond Paper
Print Controller Specifications
CPU 295MHz
Memory 64 MB RAM standard/maximum
Standard Interfaces USB 2.0, Ethernet 10/100Base-TX
Printer Languages/Drivers 1 PCL 6, PostScript 3 emulation
Fonts PCL/PS 3: 80 fonts
Network Protocols TCP/IP, IPP
Operating Systems Windows 2000, XP, Server 2003/2008R2 2 , Vista, 7 2
Macintosh OS X v.10.2.8 – 10.6 2
Citrix Presentation Server
Ricoh UNIX Filter 3
Advanced Printer Features Scaling, Collate, Layout/N-Up, Front Cover Sheet,
Dithering, Watermarks, Rotate Print, Toner Saving,
Mirror Image (PS3), Reverse Order Print (PS3),
Do Not Print Blank Pages (PS3)
Software Utilities Web Image Monitor (when connected to a LAN)
Printer Utility for Mac
@Remote (limited support)
1 PCL 5e does not ship with the product, but the controller can receive PCL 5e information from
the host computer.
2 Available via download from the Ricoh website. 3 Please check www.ricoh-usa.
com for final release date.
Optional Accessories
250-Sheet Paper Feed Unit TK1080 (Part # 406496)
Ricoh BB-HPL10A-R High Definition Power Line
Communications Ethernet Adaptor (Part # 100123FNG)
Ships with one Master Adaptor, one Terminal Adaptor, plus two power cords.
Additional Adaptors can be purchased separately
USB Cable (A - B) 6’ (Part # 004051MIU)
Supplies
Standard Yield All-In-One Cartridge (Part # 406464; yield: 2,500 pages 4 )
High Yield All-In-One Cartridge (Part # 406465; yield: 5,000 pages 4 )
4 Declared yield values based on ISO/IEC 19752. Actual yields may vary based on types of images
printed and other factors. The Ricoh Aficio SP 3400N/SP 3410DN ships with a starter All-In-One print
cartridge yielding 1,500 pages. All other consumables ship at full yield.
For maximum performance and yield, we recommend using genuine Ricoh parts and supplies.
Warranty
The Ricoh Aficio SP 3400N/SP 3410DN is under warranty against defects for a
period of one year from the date of purchase. Consumables are under warranty
for a period of 90 days from the date of purchase. Please refer to warranty
documents shipped with the product for more details.
www.ricoh-usa.com
Ricoh Americas Corporation, Five Dedrick Place, West Caldwell, NJ 07006
Ricoh
® and the Ricoh Logo are registered trademarks of Ricoh Company,
Ltd. All other trademarks are the property of their respective owners.
Print speed may be affected by network, application or PC performance.
Specifications and external appearances are subject to change without
notice. Products are shown with optional features.
