RD74LVC04B
Rev.1.00, Apr.08.2004, page 4 of 7
Electrical Characteristics
Ta = –40 to 85°C
Item Symbol V
CC
(V) Min Max Unit Test Conditions
1.65 to 1.95 V
CC
×
0.65 —
2.3 to 2.7 1.7 —
2.7 to 3.6 2.0 —
V
IH
4.5 to 5.5 V
CC
×
0.7 —
V
1.65 to 1.95 — V
CC
×
0.35
2.3 to 2.7 — 0.7
2.7 to 3.6 — 0.8
Input voltage
V
IL
4.5 to 5.5 — V
CC
×
0.3
V
1.65 to 5.5 V
CC
–0.2 — I
OH
= –100 µA
1.65 1.2 — I
OH
= –4 mA
2.3 1.7 — I
OH
= –8 mA
2.7 2.2 —
3.0 2.4 —
I
OH
= –12 mA
3.0 2.2 —
V
OH
4.5 3.8 —
V
I
OH
= –24 mA
1.65 to 5.5 — 0.2 I
OL
= 100 µA
1.65 — 0.45 I
OL
= 4 mA
2.3 — 0.7 I
OL
= 8 mA
2.7 — 0.4 I
OL
= 12 mA
3.0 — 0.55
Output voltage
V
OL
4.5 — 0.55
V
I
OL
= 24 mA
Input current I
IN
0 to 5.5 — ±5.0 µA V
IN
= 5.5 V or GND
2.7 to 3.6 — ±5.0 V
IN
= 3.6 V to 5.5 V I
CC
2.7 to 5.5 — 5.0
µA
V
IN
= V
CC
or GND
Quiescent supply
current
∆
I
CC
2.7 to 3.6 — 500 µA V
IN
= one input at
(V
CC
–0.6)V,
other inputs at V
CC
or GND
