RD74LVC04B
Rev.1.00, Apr.08.2004, page 3 of 7
Recommended Operating Conditions
Item Symbol Ratings Unit Conditions
1.5 to 5.5 Data hold Supply voltage V
CC
1.65 to 5.5
V
At operation
V
I
0 to 5.5 A Input / Output voltage
V
O
0 to V
CC
V
Y
Operating temperature Ta –40 to 85 °C
–4 V
CC
= 1.65 V
–8 V
CC
= 2.3 V
–12 V
CC
= 2.7 V
I
OH
–24
mA
V
CC
= 3.0 V to 5.5 V
4 V
CC
= 1.65 V
8 V
CC
= 2.3 V
12 V
CC
= 2.7 V
Output current
I
OL
24
mA
V
CC
= 3.0 V to 5.5 V
20 V
CC
= 1.65 V to 2.7 V Input rise / fall time
*1
t
r
, t
f
10
ns/V
V
CC
= 3.0 V to 5.5 V
Notes: 1. This item guarantees maximum limit when one input switches.
Waveform: Refer to test circuit of switching characteristics.
