5
TOOLS NEEDED
The following information will indicate some tools and
materials necessary for a complete installation:
• 4 twisted pair communication wire (commonly referred to
as CAT-5). This wire will be used to connect the keypads
in each zone to the controller. Stranded, 16 Gauge mini-
mum, CL3 rated wire. This wire is used for direct connec-
tion between the CAi and your speakers.
• 110 Punchdown tool (included)
• A medium sized flat-head screwdriver.
• Wire strippers and cutters
• Electric drill and a 1/2" x 6" drill bit
• A steel-wire fish tape
• A keyhole saw
• Electrical junction boxes (6)
• A stud finder
• A screwdriver (cordless recommended)
• Misc. hand tools, nails & screws
• Cable staples
• Modular RJ-45 crimper and connectors
If you have problems or you are not absolutely comfortable
with what you are doing, consult a professional carpenter,
electrician, or system installer.
BASIC PLANNING AND LAYOUT CONSIDERATIONS
• Where will the speakers be located?
• Where will the keypads be located?
• How will the wiring be routed to each location?
• Where is the source equipment located?
• Where is the CAi controller going to be located?
CONNECTION TIPS
• Disconnect all power cords before connecting to the CAi.
• Verify that all connections and polarity are correct.
• Keep all power cords away from all signal cables to pre-
vent noise or humming.
• Choose reliable signal cables / patch cords.
• Label all wires with room location at both ends of the
wire.
G
ETTING
S
TARTED
Speaker Wire Length Gauge of Speaker Wire
10-100 feet 16 AWG
100-150 feet 14 AWG
Over 150 feet 12 AWG
Keypad Control Max Recommended
Wire Type Wire Length
CAT-5 250 feet
