Ricoh Priport DX 4640
PD
System Specifications
General Specifications
Master processing Digital/Printer controller built-in
Printing process Press Roller System
Original type Sheets, Book
Original size Maximum 11.8" x 17.0"
Pixel density Scanning: 600 dpi X 400 dpi
Master-making: 400 dpi X 400 dpi
Image mode – Letter mode
– Letter / Photo auto separation
Contrast: strong, standard, soft
– Photo mode
Dots pattern: standard, rough
(4 levels)
Contrast: high, standard, low
– Tint mode
– Pencil mode
Image density 4 levels: Lighter, Normal, Dark,
Very dark
Reproduction ratio 6 Reduction and 5 Enlargement:
50%, 65%, 74%, 77%, 85%, 93%
100%, 121%, 129%, 155%, 200%
Zoom 50–200 % (in 1 % step)
Directional magnification 50–200 % (in 1 % step, in
1 mm step)
Auto magnification Available
selection
Printing area 10.8" x 16.6"
(One-sided print)
Leading edge margin Less than 6 mm
Print paper size Maximum: 12.8" x 17.6"
(One-sided print) Minimum: 2.8" x 5.8"
Print paper weight 13 lb. Bond – 110 lb. Index
(One-sided print)
First print time Portrait: 12 sec.
(One-sided print)
Image position Vertical: ± 0.39"
(One-sided print) Horizontal: ± 0.39"
Minimum movable unit: 0.01"
Printing speed 60–135 sheets / minute for
(One-sided print) 8.5" x 11" and below (6 levels)
60–120 sheets / minute for
11" x 17" (5 levels)
Paper feed table capacity 1,000 sheets (20 lb. paper)
Paper delivery table capacity 1,000 sheets (20 lb. paper)
Master feed capacity
More than 200 masters / roll
Ejected master capacity DLT: More than 100 masters
Color drum change Available
Conserving master Available
Auto color detection Available
Auto density control Available
Auto shut-off Available
Security mode Available (Higher / Normal)
User code Up to 200 codes
Class Available
Program mode Available (10 programs)
Skip feed (One-sided only) Available
User tool
Available
Margin erase Available
Auto background Available
correction
Image rotation Available
Original storage Available
Multiple copy mode Combine printing: 2 in 1, 4 in 1
Repeat printing: 2 in 1, 4 in 1,
8 in 1, 16 in 1 and custom
Overlay (One-sided print) Available
Stamping (One-sided print) Available
Quality start
Available
Power source 120V, 60Hz
Dimensions (W x D x H) with table
Platen cover: 55.90" x 28.34" x 40.15"
ARDF: 55.90" x 28.34" x 44.48"
Net Weight Without table
Machine with Platen cover: 261.24 lb.
Machine with ADF: 278.88 lb.
Printing area (Duplex) 10.8" x 8"
Print paper size (Duplex) Only 8.5" x 11"
Print paper weight (Duplex) 17 lb. to 28 lb. Bond
First print time (Duplex)
ADF
8.5" x 11" portrait duplex print:
46 seconds (One-sided original)
8.5" x 11" portrait duplex print:
50 seconds (Duplex original)
Image position (Duplex) Vertical: ±0.1"
Horizontal: ± 0.39"
Minimum movable unit: 0.01"
Printing speed (Duplex) 120–240 images / minute (5 levels)
(60–120 sheets / minute (5 levels))
General Features of Printer Controller
CPU TX4955–300MHz
RAM 128 MB (Resident 64 MB + 64 MB
additional memory)
Note: Additional 64 MB Memory is pre-installed.
Hard Disk Drive Option
PDL RPCS
Adobe
® PostScript ® 3 ™ (Option)
Print Resolution 400 dpi x 400 dpi
Fonts RPCS: Arial
PS3: 136 Adobe
® PostScript ® fonts
(Option)
Host Interface Ethernet (Ethernet
100BaseTX/10BaseT)
USB 2.0
IEEE802.11b (Wireless LAN)
Interface (Option)
Parallel Port IEEE1284 (Option)
Note: Only one of above option can be installed.
Network Protocol TCP/IP, IPX/SPX, NetBEUI, AppleTalk
MIB support PrinterMIB
Network/Operating Windows95/98/Me/NT4.0/
Systems 2000/XP/Server2003
Mac OS 8.6 – 9.X, Mac OS X
(10.1 – 10.4)
Note: Mac OS only works for PS3
Controller Options
Extension HDD Type 1 40 GB (6 GB for document storage)
Memory Unit Type C SDRAM
(128 MB/256 MB)
PostScript 3 Board Type 2 Module type ROM DIMM
IEEE 802.11b I/F Unit Type 1
Protocol
TCP/IP, NetBEUI, IPX/SPX, AppleTalk
Data transfer speed Auto select from below speed
1Mbps, 2Mbps, 5.5Mbps, 11Mbps
Frequency range 2412–2462 MHz (1–11 channels)
Transmittable distance 1Mbps 400 m
2Mbps 270 m
5.5Mbps 200 m
11Mbps 140 m
Transmission mode 802.11 ad-hoc, ad-hoc, and
infrastructure mode
IEEE 1284 Parallel Board Standard IEEE 1284 compliant
Type 1 Micro Centronics 36 pin cable
Auto Document Feeder
Product name ARDF Type 4640
Simplex Standard sized papers:
DLT, LT, LG
Non-standard sized papers:
Vertical: 4.2" – 11.7"
Horizontal: 5.1" – 34"
Duplex DLT, LT, LG,
Original weight 14 to 28 lb.
Simplex Standard sized papers: 14 to 34 lb.
Non-standard sized papers:
14 to 28 lb.
Duplex 14 to 28 lb.
Original table capacity 50 sheets (20 lb. paper)
Power source From mainframe
Dimensions (W x D x H) W 21.65" x D 18.50" x H 5.11"
Net Weight 22.04 lb.
TC-IIR (Twin color printing system)
Product name TC-IIR
Configuration Floor Standing (with optional cabinet)
Master processing No master making unit
Printing process Twin color press roller printing
system
Printing area 11.4" x 16.0"
Print paper size Maximum 12.8" x 17.3"
Minimum 2.8" x 9.8"
Print paper weight 12.5 lb. Bond – 110 lb. Index
Image position
1st drum Vertical; ±15 mm
Horizontal; ± 10 mm
2nd drum Vertical; ± 5 mm
Horizontal; ± 10 mm
Minimum movable unit 0.125 mm
(2nd drum)
Printing speed 90–120 sheets / minute
(90,105,120 cpm)
Skip feed Available
Friction control Available
Paper type selection Available
Auto switch off Available
Paper feed table capacity 1,000 sheets (20 lb. paper)
Paper delivery table capacity 1,000 sheets (20 lb. paper)
Paper counter
Standard
Color drum change Available
Power source 110 – 120V, 60Hz
Power consumption 120cpm printing: 550W
Dimensions (W x D x H) W: 61.22" x D: 24.80" x
H: 21.85"
Weight 194 lb.
With 2 drums 227.07 lb.
LCS (Large capacity system)
Product name LS3000R
Configuration Consists of two parts:
Large Capacity Input Tray (LCIT)
Large Capacity Output Tray (LCOT)
LCIT can be used independently
Paper feed tray stack 3,000 sheets (20 lb.)
capacity
Paper delivery tray stack 3,000 sheets (20 lb.)
capacity
Delivery paper size Max: 11.69" x 17"
Min: 5" x 7.16"
Delivery paper weight 12.5 lb. Bond – 110 lb. Index
Available Ink Colors
Standard color inks Red, Green, Blue, Grey, Orange,
Maroon, Yellow, Teal, Brown,
Navy, Purple, Burgundy, Hunter
green, Violet, Gold, Reflex blue
CM (Custom) color inks Available
