www.RuggedCom.com 8 RuggedSwitch ® M2200
RuggedSwitch
®
M2200
MIL-STD 9-Port Managed Gigabit Ethernet Switch
M2200 -______ -______ -____ -____ -____ -____ -____ -____ -____
Main Mount PS1 PS2 S1 S2 S3 S4 S5
Main: Ethernet and Power Connectors
. B = Ethernet on rear; LED panel on top; power connector on rear
. T = Ethernet on front; LED panel on top; power connector on rear
. R = Ethernet on rear; LED panel on front; power connector on rear
. F = Ethernet on front; LED panel on front; power connector on rear
Mount: Mounting Options
. DP = Panel Mount Kit
. RM = 19” Rack Mount Kit 2
. 00 = No Mounting Option
PS1 and PS2: Power Supply 1 and 2
. 24 = 24VDC (9-36VDC), screw terminal block
. 48 = 48VDC (36-59VDC), screw terminal block
. HI = 88-300VDC or 85-264VAC, screw terminal block
. XX = No Power Supply (PS2 Only)
S1, S2, S3, S4: Gigabit Ethernet Modules
for Slots 1, 2, 3, and 4
. XXXX = Empty
. CG02 = 2 x 10/100/1000Tx Micro-D
. FG01 = 2 x 1000SX - Multimode, 850nm, LC, 500m
. FG03 = 2 x 1000LX - Singlemode, 1310nm, LC connectors, 10km
. FG05 = 2 x 1000LX - Singlemode, 1310nm, LC connectors, 25km
S5: Gigabit Ethernet Modules for Slot 5
. XXXXX = Empty
. 1CG02 = 1 x 10/100/1000Tx Micro-D
. 1FG01 = 1 x 1000SX - Multimode, 850nm, LC, 500m
. 1FG03 = 1 x 1000LX - Singlemode, 1310nm, LC connectors, 10km
. 1FG05 = 1 x 1000LX - Singlemode, 1310nm, LC connectors, 25km
NOTES:
1 Distance ratings are typical but will depend on type of cabling, number of connectors and splices.
2 The unit is not rated for vibration and shock, MIL-STD-901D, while configured with the rack mount kit.
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Example Order Codes:
M2200-B-DP-24-XX-FG03-FG03-XXXX-XXXX-XXXXX
Panel Mount Kit, Single 24VDC power supply, 4 1000LX Gigabit
Ethernet Ports (Singlemode 1310nm fiber, LC connectors), with
Ethernet ports on the rear
M2200-B-DP-48-48-CG01-CG02-FG02-FG01-XXXX-XXXXX
Panel Mount Kit, Dual 48VDC power supplies, 4 10/100/1000
Ethernet Ports, 4 1000SX Gigabit Ethernet Ports (Multimode
1300nm fiber, LC connectors) Ethernet ports, with Ethernet ports
on the rear.
M2200-B-DP-HI-48-FG03-FG03-FG03-FG03-1FG03
Panel Mount Kit, Dual power supplies (HI and 48VDC),
9 1000LX Gigabit Ethernet Ports Singlemode, 1300nm, LC
connectors, with Ethernet ports on the rear.
Order Codes
M2200
