www.RuggedCom.com 5 RuggedSwitch ® M2200
RuggedSwitch
®
M2200
MIL-STD 9-Port Managed Gigabit Ethernet Switch
IEC 61850-3 EMI TYPE TESTS
TEST Description Test Levels Severity Levels
IEC 61000-4-2 ESD
Enclosure Contact +/- 8kV 4
Enclosure Air +/- 15kV 4
IEC 61000-4-3 Radiated RFI Enclosure ports 20 V/m x
IEC 61000-4-4 Burst (Fast Transient)
Signal ports +/- 4kV @ 2.5kHz x
D.C. Power ports +/- 4kV 4
A.C. Power ports +/- 4kV 4
Earth ground ports 3 +/- 4kV 4
IEC 61000-4-5 Surge
Signal ports +/- 4kV line-to-earth, +/- 2kV line-to-line 4
D.C. Power ports +/- 2kV line-to-earth, +/- 1kV line-to-line 3
A.C. Power ports +/- 4kV line-to-earth, +/- 2kV line-to-line 4
IEC 61000-4-6 Induced (Conducted) RFI
Signal ports 10V 3
D.C Power ports 10V 3
A.C. Power ports 10V 3
Earth ground ports 3 10V 3
IEC 61000-4-8 Magnetic Field Enclosure ports 40 A/m continuous, 1000 A/m for 1 s N/A
IEC 61000-4-29
Voltage Dips & Interrupts
D.C. Power ports 30% for 0.1s, 60% for 0.1s, 100% for 0.05s N/A
A.C. Power ports
30% for 1 period, 60% for 50 periods N/A
IEC 61000-4-11 100% for 5 periods, 100% for 50 periods 2 N/A
IEC 61000-4-12 Damped Oscillatory
Signal ports 2.5kV common, 1kV diff. mode@1MHz 3
D.C. Power ports 2.5kV common, 1kV diff. mode@1MHz 3
A.C. Power ports 2.5kV common, 1kV diff. mode@1MHz 3
IEC 61000-4-16 Mains Frequency Voltage
Signal ports 30V Continuous, 300V for 1s 4
D.C. Power ports 30V Continuous, 300V for 1s 4
IEC 61000-4-17 Ripple on D.C. Power Supply D.C. Power ports 10% 3
IEC 60255-5 Dielectric Strength
Signal ports 2kVac (Fail-Safe Relay output) N/A
D.C. Power ports 2kVac N/A
A.C. Power ports 2kVac N/A
IEC 60255-5 H.V. Impulse
Signal ports 5kV (Fail-Safe Relay output) N/A
D.C. Power ports 5kV N/A
A.C. Power ports 5kV N/A
IEEE 1613 (C37.90.x) EMI IMMUNITY TYPE TESTS
Test Description Test Levels Severity Levels
IEEE C37.90.3 ESD
Enclosure Contact +/- 8kV N/A
Enclosure Air +/- 15kV N/A
IEEE C37.90.2 Radiated RFI Enclosure ports 35 V/m N/A
IEEE C37.90.1 Fast Transient
Signal ports +/- 4kV @ 2.5kHz N/A
D.C. Power ports +/- 4kV N/A
A.C. Power ports +/- 4kV N/A
Earth ground ports3 +/- 4kV N/A
IEEE C37.90.1
Oscillatory
Signal ports 2.5kV common mode @1MHz N/A
D.C. Power ports 2.5kV common, 1kV diff. mode@1MHz N/A
A.C. Power ports 2.5kV common, 1kV diff. mode@1MHz N/A
IEEE C37.90 H.V. Impulse
Signal ports 5kV (Fail-Safe Relay output) N/A
D.C. Power ports 5kV N/A
A.C. Power ports 5kV N/A
IEEE C37.90 Dielectric Strength
Signal ports 2kVac N/A
D.C. Power ports 2kVac N/A
A.C. Power ports 2kVac N/A
MILITARY STANDARD TESTS
MIL-STD Description Details
MIL-STD-901D * Shock (Hard-Mounted) Grade A, Equipment Class I, Shock Type A Equipment
MIL-STD-167-1 * Vibration Type I (Upper Frequency of 33 Hz)
MIL-STD-461E * Electromagnetic Interference
CE101, CE102, CS101, CS114, CS115, CS116, RE101, RE102,
RS101, RS103
MIL-STD-1399 * Magnetic Field - DC Magnetic Exposure Section 070, Part 1
MIL-STD-810F * Temperature - Low/High Temperature Method 501
MIL-STD-810 * Temperature - Non-operating Thermal Shock Method 503
MIL-STD-810 * Humidity Method 507, Procedure IV
Notes: 1. Only applicable to functional earth connections separated from the safety earth connection.
2. Class 2 refers to "Measuring relays and protection equipment for which a very high security margin is required or where
the vibration levels are very high, ( e.g. shipboard application and for severe transportation conditions")
* Testing complete, pending final documentation (contact RuggedCom for complete details)
EMI and Environmental Type Tests
