CHANGE OF THE DOOR HINGING
1. Set the temperature adjustment knob to "0"
and unplug the appliance.
2. Remove food from the appliance.
3. Unscrew the fridge top cover
(Photo 6).
6
7
4. Remove the top cover from the fridge
(photo 7).
8
6. Tilt the fridge back approx. 40° to gain
access to the lower hinge.
7. Unscrew the lower hinge (photo 9).
9
5. Unscrew the upper hinge, remove the frid-
ge door and set it aside in a safe place (photo
8).
8. Unscrew the adjustable foot (photo 10).
9. Using the same method transfer the up-
per, middle and lower hinge to the opposite
side of the door.
10. Once the door is attached, please make
sure it is correctly aligned with the appliance
body. Door edge should be parallel to the
edge of the appliance body. Adjustments are
made to the middle hinge using a Phillips
screwdriver (star screwdriver).
11. Switch on the fridge as described in the
relevant section of its operating instructions.
10
