Radio Shack 63-5086 User Manual

Page 2

07A02
63-5086

Printed in China

4GECNNKPI"VJG"4GEQTFU

1. To review the records of your previous

games, select the recall mode.

appears on the center of the upper row,
or

DEýH;9

appears if there is no record.

2. Press

STROKE

to recall the previous

game or press

PUTT

to recall the next

game.

3. Press

TOTAL

to move through FRONT,

BACK or FINAL records of the recalled
game.

You can also delete game records in the
recall mode.

1. To delete a record, hold down

SET

for

2-3 seconds.

9BH

appears on the right

upper corner of the display.

2. Press

SET

to delete the current record.

To cancel deletion, press

STROKE

PUTT

while

9BH

appears.

5GVVKPI"VJG"#NCTO"

1. To set the watch’s alarm, select the

alarm mode.

appears on the left

upper corner of the display.

2. Hold down

SET

for 2-3 seconds. The

hour digit flashes.

3. Press or hold down

STROKE

PUTT

increase the digit(s). Then press

MODE

the minute digits flash.

4. Press or hold down

STROKE

PUTT

increase the digit(s).

5. Press

SET

to confirm.

appears

automatically.

6. Repeatedly press

TOTAL

to turn on or

off alarm or chime function.

and

appear or disappear accordingly. A
chime signal sounds every hour if

appears.

The alarm sounds at the alarm time for 20
seconds, press any button to silence the
alarm.

5+0)

6*'

*4101)4#2*

1. To use the stopwatch, select the

chronograph mode.

appears on the

left upper corner of the display.

2. To reset the stopwatch, press

PUTT

while the stopwatch is not counting.

3. To start the stopwatch counting from

zero, press

STROKE

4. To take the split time, press

PUTT

(

IFB

appears).

5. To continue the original counting, press

PUTT

again (

IFB

disappears).

6. Press

STROKE

to stop the counting, and

press again to continue.

4GRNCEKPI"VJG"$CVVGT[

The watch comes with one CR 2025 type
lithium button-cell battery for power. When
the screen looks dim or the sound becomes
weak, replace the battery. All records are
cleared when the battery is removed.

For the best performance and longest life,
we recommend a RadioShack lithium
battery.

Rý

1. To replace the battery, place the watch

on a solid surface with the display
facing down.

2. Hold the watch firmly and use a small,

flat-blade screwdriver (not supplied) to
press the spring-bars inwards, and
remove the watchband.

3. Use the screwdriver to remove the four

screws from the watch’s back cover,
then remove the cover.

4. Use the screwdriver to remove the

screw from the battery cap, then
remove the cap.

5. Remove the old battery and install the

new one, positive (+) side facing up.

6. Replace the cap and cover and secure

them with screws.

7. Hold the watch firmly, and use the

screwdriver to slide the spring-bars into
their holes on the watch to secure the
watchband.

#4'

Keep the watch dry; if it gets wet, wipe it dry
immediately. Use and store the watch only
in normal temperature environments.
Handle the watch carefully; do not drop it.
Keep the watch away from dust and dirt, and
wipe it with a damp cloth occasionally to
keep it looking new.

If your watch is not performing as it should,
take it to your local RadioShack store for
assistance. Modifying or tampering with the
watch’s internal components can cause a
malfunction and might invalidate its
warranty.

52'%+(+%#6+105

Power ....................... One CR2025 3V Button Cell

Battery Life .............................................One Year

Accuracy........................................ ±0.67 Sec/Day

Dimensions (w/o band) .. 2

Inches

(52

13 mm)

Accessories ................................Golf Tees (2 pcs)

.............................................. Ball Markers (2 pcs)

"9#40+0)"

• Keep button-cell batteries away from

children. Swallowing a button-cell battery
can be fatal.

• Dispose of old batteries promptly and

properly. Do not burn or bury them.

"%#76+10"

Use only a fresh battery of the required size
and recommended type.

Limited One-Year Warranty

This product is warranted by RadioShack against
manufacturing defects in material and workmanship
under normal use for one (1) year from the date of
purchase from RadioShack company-owned stores
and authorized RadioShack franchisees and dealers.
EXCEPT AS PROVIDED HEREIN, RadioShack
MAKES NO EXPRESS WARRANTIES AND ANY IM-
PLIED WARRANTIES, INCLUDING THOSE OF
MERCHANTABILITY AND FITNESS FOR A PAR-
TICULAR PURPOSE, ARE LIMITED IN DURATION
TO THE DURATION OF THE WRITTEN LIMITED
WARRANTIES CONTAINED HEREIN. EXCEPT AS
PROVIDED HEREIN, RadioShack SHALL HAVE NO
LIABILITY OR RESPONSIBILITY TO CUSTOMER
OR ANY OTHER PERSON OR ENTITY WITH RE-
SPECT TO ANY LIABILITY, LOSS OR DAMAGE
CAUSED DIRECTLY OR INDIRECTLY BY USE OR
PERFORMANCE OF THE PRODUCT OR ARISING
OUT OF ANY BREACH OF THIS WARRANTY, IN-
CLUDING, BUT NOT LIMITED TO, ANY DAMAGES
RESULTING FROM INCONVENIENCE, LOSS OF
TIME, DATA, PROPERTY, REVENUE, OR PROFIT
OR ANY INDIRECT, SPECIAL, INCIDENTAL, OR
CONSEQUENTIAL DAMAGES, EVEN IF Ra-
dioShack HAS BEEN ADVISED OF THE POSSIBIL-
ITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of
incidental or consequential damages, so the above
limitations or exclusions may not apply to you.
In the event of a product defect during the warranty
period, take the product and the RadioShack sales
receipt as proof of purchase date to any RadioShack
store. RadioShack will, at its option, unless otherwise
provided by law: (a) correct the defect by product re-
pair without charge for parts and labor; (b) replace
the product with one of the same or similar design; or
(c) refund the purchase price. All replaced parts and
products, and products on which a refund is made,
become the property of RadioShack. New or recondi-
tioned parts and products may be used in the perfor-
mance of warranty service. Repaired or replaced
parts and products are warranted for the remainder
of the original warranty period. You will be charged
for repair or replacement of the product made after
the expiration of the warranty period.
This warranty does not cover: (a) damage or failure
caused by or attributable to acts of God, abuse, acci-
dent, misuse, improper or abnormal usage, failure to
follow instructions, improper installation or mainte-
nance, alteration, lightning or other incidence of ex-
cess voltage or current; (b) any repairs other than
those provided by a RadioShack Authorized Service
Facility; (c) consumables such as fuses or batteries;
(d) cosmetic damage; (e) transportation, shipping or
insurance costs; or (f) costs of product removal, in-
stallation, set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you
may also have other rights which vary from state to
state.

RadioShack Customer Relations, 200 Taylor Street,

6th Floor, Fort Worth, TX 76102

12/99
