P.12
3.3 How to Use the Slides
Chapter 3
Figure 7 .
■
A black arrow release button is located on the
outside of each slide. (shown in Figure 7).
Figure 8 .
■
Pull and hold the black arrow button on either
side of the LCD drawer to unlock.
(shown in Figure 8).
Figure 9 .
■
Push the LCD drawer into the rack. (shown in
Figure 9).
Caution : Keep your fi ngers away from the
slide stop
L
I
L
I
RP-W119QD
