www.RuggedCom.com 8 RuggedServer™ RS910
RuggedServer™ RS910
2-Port Serial Device Server with up to 3 Ports Managed Ethernet Switch
RS910 -_____ -____ -____ -____ -_____
PS M S E1 E2
PS: Power Supply
„ „ 24 = 24 VDC (9-36 VDC)
48 = 48 VDC (36-72 VDC) „ „
HI = 85-264VAC or 88-300VDC „ „
M: Mounting options
D = Din Rail „ „
P = Panel Mounting „ „
N = None „ „
S: Serial Port Options
XX = None „ „
S1 = 2 x RS232/422/485 DB9 „ „
S2 = 2 x RS232/422/485 RJ45 „ „
S3 = 2 x Fiber 850nm ST „ „
E1: Ethernet Ports Options
XXXX = No Ethernet ports „ „
TX01 = 2 x 10/100TX RJ45 „ „
FL01 = 2 x 10FL - Multimode, 850 nm, ST connectors „ „
FX01 = 2 x 100FX - Multimode, 1300 nm, ST connectors „ „
FX02 = 2 x 100FX - Multimode, 1300 nm, SC connectors „ „
FX03 = 2 x 100FX - Multimode, 1300 nm, MTRJ connectors „ „
FX11 = 2 x 100FX - Multi mode, 1300nm, LC connectors „ „
FX04 = 2 x 100FX - Singlemode, 1300 nm, ST connectors, 20km „ „
FX05 = 2 x 100FX - Singlemode, 1300 nm, SC connectors, 20km „ „
FX06 = 2 x 100FX - Singlemode, 1300 nm, LC connectors, 20km „ „
FX07 = 2 x 100FX - Singlemode, 1300 nm, SC connectors, 50km „ „
FX08 = 2 x 100FX - Singlemode, 1300 nm, LC connectors, 50km „ „
FX09 = 2 x 100FX - Singlemode, 1300 nm, SC connectors, 90km „ „
FX10 = 2 x 100FX - Singlemode, 1300 nm, LC connectors, 90km „ „
E2: Ethernet Ports Options
XX = No port „ „
TX = 1 x 100BaseTX „ „
MJ = 1 x 100BaseFX - Multimode, MTRJ connector „ „
MC = 1 x 100BaseFX - Multimode, SC connector „ „
MT = 1 x 100BaseFX - Multimode, ST connector „ „
ML = 1 x 100BaseFX - Multimode, LC connector „ „
T2 = 1 x 100BaseFX - Singlemode, ST connector, 20km „ „
L2 = 1 x 100BaseFX - Singlemode, LC connector, 20km „ „
L5 = 1 x 100BaseFX - Singlemode, LC connector, 50km „ „
L9 = 1 x 100BaseFX - Singlemode, LC connector, 90km „ „
C2 = 1 x 100BaseFX - Singlemode, SC connector, 20km „ „
C5 = 1 x 100BaseFX - Singlemode, SC connector, 50km „ „
C9 = 1 x 100BaseFX - Singlemode, SC connector, 90km „ „
Order Code
