Ridge Tool Company/Elyria, Ohio, U.S.A.
6
Pipe and Bolt Threading Machine
1233
3
1
2
4
5
6
7
8
9
10
12
13
14
17
18
15
16
19
20
21
22
23
24
25
26
27
11
No. 724 NPT & 924 BSPT
1
/
2
″
-
3
/
4
″
Die Heads
No. 726 NPT & 926 BSPT 1
″
- 2
″
Die Heads
NOTE: Order parts by Catalog Number only.
DO NOT order by Reference Number.
Ref.
Catalog
No.
No.
Description
—
50317
924
1
/
2
″
-
3
/
4
″
BSPT Die Head
—
50322
926 1
″
- 2
″
BSPT Die Head
—
54447
724
1
/
2
″
-
3
/
4
″
NPT Die Head
—
54442
726 1
″
- 2
″
NPT Die Head
1
32205
Screw
1
/
4
″
- 20 x
5
/
8
″
SHCS (4)
2
60097
Detente Plunger (4)
3
52292
Retaining Ring
1
/
2
″
-
3
/
4
″
, 1
″
- 2
″
4
61587
Jam Nut
3
/
8
″
5
61592
Flat Washer
3
/
8
″
6
61607
Adjuster Bolt
7
61602
Adjuster Plunger
8
52342
Adjuster Spring
9
52447
Screw #10-24 x
1
/
2
″
FHCS (6)
10
52312
Cam Plate BSPT 924,
1
/
2
″
-
3
/
4
″
52317
Cam Plate BSPT 926, 1
″
- 2
″
56067
Cam Plate NPT 724,
1
/
2
″
-
3
/
4
″
56072
Cam Plate NPT 726, 1
″
- 2
″
Ref.
Catalog
No.
No.
Description
11
52442
Support Ring
12
34877
Soc. Hd. Shoulder Bolt
1
/
4
″
x
1
/
2
″
13
61617
Rocker Release Assembly
14
52377
Slide Roller Bearing (2)
15
58667
Adjuster Slide
16
61612
Release Spring
17
61597
Adjuster Knob
18
52372
Spring Retainer (2)
19
87940
Roll Pin
1
/
4
″
x
7
/
8
″
20
52387
Trigger Spring
21
52397
Spring Mounting Pin
22
60092
Trigger Spring
23
45750
Screw #10-24 x
3
/
8
″
SHCS (2)
24
52417
Adjustable Trigger
25
52422
Trigger Pivot
26
59832
Die Head Post
27
52432
Die Head w/Post
