CHAPTER 5 EXPLANATION OF INSTRUCTIONS

User's Manual U12326EJ4V0UM

And

AND

Logical Product of Byte Data

[Instruction format]

AND dst, src

[Operation]

dst

← dst ∧ src

[Operand]

Mnemonic

Operand(dst,src)

Mnemonic

Operand(dst,src)

AND

A, #byte

AND

A, !addr16

saddr, #byte

A, [HL]

A, r

Note

A, [HL+byte]

r, A

A, [HL+B]

A, saddr

A, [HL+C]

Note Except r = A

[Flag]

[Description]

•

Bit-wise logical product is obtained from the destination operand (dst) specified by the 1st operand and the

source operand (src) specified by the 2nd operand and the result is stored in the destination operand (dst).

•

If the logical product shows that all bits are 0, the Z flag is set (1). In all other cases, the Z flag is cleared

(0).

[Description example]

AND FEBAH, #11011100B; Bit-wise logical product of FEBAH contents and 11011100B is obtained and the

result is stored at FEBAH.
