36
CHAPTER 4 INSTRUCTION SET
User's Manual U12326EJ4V0UM
2nd Operand A.bit sfr.bit saddr.bit PSW.bit [HL].bit CY $addr16 None
1st Operand
A.bit MOV1 BT SET1
BF CLR1
BTCLR
sfr.bit MOV1 BT SET1
BF CLR1
BTCLR
saddr.bit MOV1 BT SET1
BF CLR1
BTCLR
PSW.bit MOV1 BT SET1
BF CLR1`
BTCLR
[HL].bit MOV1 BT SET1
BF CLR1
BTCLR
CY MOV1 MOV1 MOV1 MOV1 MOV1 SET1
AND1 AND1 AND1 AND1 AND1 CLR1
OR1 OR1 OR1 OR1 OR1 NOT1
XOR1 XOR1 XOR1 XOR1 XOR1
2nd Operand #word AX rp Note sfrp saddrp !addr16 SP None
1st Operand
AX ADDW MOVW MOVW MOVW MOVW MOVW
SUBW XCHW
CMPW
rp MOVW MOVW Note INCW
DECW
PUSH
POP
sfrp MOVW MOVW
saddrp MOVW MOVW
!addr16 MOVW
SP MOVW MOVW
Note Only when rp = BC, DE or HL.
(2) 16-bit instructions
MOVW, XCHW, ADDW, SUBW, CMPW, PUSH, POP, INCW, DECW
(3) Bit manipulation instructions
MOV1, AND1, OR1, XOR1, SET1, CLR1, NOT1, BT, BF, BTCLR
