NEC 78K/0 Series - Manual (Page 108)

108
CHAPTER 5 EXPLANATION OF INSTRUCTIONS
User's Manual U12326EJ4V0UM
Branch if Carry
BC
Conditional Branch with Carry Flag (CY = 1)
[Instruction format] BC $addr16
[Operation] PC ← PC+2+jdisp8 if CY = 1
[Operand]
Mnemonic Operand($addr16)
BC $addr16
[Flag]
Z AC CY
[Description]
• When CY = 1, data is branched to the address specified by the operand.
When CY = 0, no processing is carried out and the subsequent instruction is executed.
[Description example]
BC $300H; When CY = 1, data is branched to 0300H (with the start of this instruction set in the range of
addresses 027FH to 037EH).
