4-12 Chapter 4: Programming Set Up
Move Cursor To Specified Position
Format: 1B 13 nn
Range: 00 ≤ nn ≤ 27 (hex)
Description: Moves the cursor to the specified position. Position 0
is the upper leftmost position, and position 27 is the lower
rightmost position. Any value outside this range is discarded, the
command is ignored, and the cursor is moved. The cursor location
always indicates the position of the next character to be displayed,
whether the cursor is enabled and blinking or not. After each
character is displayed, the firmware performs a logical Move
Cursor Right command. The character positions are shown in the
following:
0 0C 0D 0E 0F 10 11 12 13
14 15 16 17 18 19 1A 1B 1C 1D 1E 1F 20 21 22 24 25 26 27 23
= Character Display Position
14526
1 2 3 4 5 6 7 8 9 0A 0B
Character Display Positions
