5

Assembly requires two persons. Set the upright bike in a cleared area and remove all packing materials. Do not
dispose of the packing materials until assembly is completed.

Assembly can be completed using the included

Hex Key (Allen wrench).

H

OW TO

A

SSEMBLE THE

U

PRIGHT

B

IKE

Insert the console wires down into the Frame (1) and
up into the Upright (3). Attach the Upright to the Frame
with six 3/8” x 1 1/4” Button Screws (53).

Make sure

that the wires are not pinched between the Upright
and the Frame.

3

Console

Wires

1

53

53

53
