8
5. Attach a Pedal (21) to the Left Pedal Leg (14)
with seven M10 x 13mm Button Screws (54),
seven M10 Split Washers (85), and seven M10
Washers (67).
Attach the other Pedal (not shown) to the Right
Pedal Leg (not shown) in the same way.
5
21
67
67
85
85
54
54
14
6. Apply a thin film of grease to the barrel of an
M10 x 65mm Bolt Set (94). Next, fit the bracket
on the Left Pedal Leg (14) onto the bracket on
the Left Track Arm (12). Attach the Left Pedal
Leg to the Left Track Arm with the Bolt Set.
Attach the Right Pedal Leg (not shown) to the
Right Track Arm (not shown) in the same way.
12
94
Grease
14
94
6
