6
1.
Attach the Stabilizer (8) to the Frame (1) with
two M10 x 116mm Carriage Bolts (38) and two
M10 Nylon Locknuts (70). Tighten two Leveling
Feet (36) into the underside of the Stabilizer.
2. Have another person hold the Upright (2) in the
position shown. Connect the Upper Wire
Harness (77) to the Lower Wire Harness (78).
Attach the Upright (2) to the Frame (1) with four
M10 x 25mm Patch Screws (48) and four M10
Split Washers (85). Make sure that no wires
are pinched between the Upright and the
Frame.
1
1
2
48
85
78
2
1
70
38
8
36
77
85
48
85
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical exerciser.
