Chapter 3: Hardware Service 3-69
PCI Riser Card
Signal Name Pin Pin Signal Name
GND 1B1 1A1 PGNT~(1)
PCICLK1 2B2 2A2 GND
GND 3B3 3A3 PGNT~(2)
PCI_REQ1# 4B4 4A4 GND
GND 5 B5 5 A5 PCICLK3
PCI_CLK2 6B6 6A6 RISER_ID1
GND 7B7 7A7 RESVD
PCI_REQ2# 8B8 8A8 RISER_ID2
GND 9B9 9A9 NOGO
PC/PCI_DREQ# 10B10 10A10 +12v
PC/PCI_DGNT# 11 B11 11A11 SER_IRQ
