Chapter 3: Hardware Service 3-61
Ethernet (CN2)
Pin Name
Function
1 TX+
Transmit
Pos
2 TX-
Transmit
Neg
3
RX+
Receive Pos
4 TERMPLANE
5 TERMPLANE
6 RX-
Receive
Neg
7 TERMPLANE
8 TERMPLANE
9
FRAME GND
10 FRAME
GND
CPU Fan (CN10)
Pin Signal
Name
1 GND
2 +12V
3 FAN_SENSE
