DS90C3202 Two-Wire Serial Interface Register Table
Address
R/W
RESET
Bit #
Description
Default Value
0d/0h
R
PWDN
[7:0]
Vender ID low byte[7:0] = 05h
0000_0101
1d/1h
R
PWDN
[7:0]
Vender ID high byte[15:8] =13h
0001_0011
2d/2h
R
PWDN
[7:0]
Device ID low byte[7:0] = 28h
0010_1000
3d/3h
R
PWDN
[7:0]
Device ID high byte 15:8] = 67h
0110_0111
4d/4h
R
PWDN
[7:0]
Device revision [7:0] = 00h to begin with
0000_0000
5d/5h
R
PWDN
[7:0]
Low frequency limit, 8Mhz = 8h
0000_1000
6d/6h
R
PWDN
[7:0]
High frequency limit 135Mhz = 87h =
0000_0000_1000_0111
1000_0111
7d/7h
R
PWDN
[7:0]
Reserved
0000_0000
8d/8h
R
PWDN
[7:0]
Reserved
0000_0000
9d/9h
R
PWDN
[7:0]
Reserved
0000_0000
10d/ah
R
PWDN
[7:0]
Reserved
0000_0000
11d/bh
R
PWDN
[7:0]
Reserved
0000_0000
20d/14h
R/W
None
[7:0]
Reserved
0000_0000
21d/15h
R/W
None
[7:0]
Reserved
0000_0000
22d/16h
R/W
None
[7:3]
Reserved
0000_0000
[2:0]
LVDS input skew control for CLK channel,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Tsetup improvement
23d/17h
R/W
None
[7]
Reserved
0000_0000
[6:4]
LVDS input skew control for RXO channel B,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Thold improvements
[3]
Reserved
[2:0]
LVDS input skew control for RXO channel C,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Thold improvements
24d/18h
R/W
None
[7]
Reserved
0000_0000
[6:4]
LVDS input skew control for RXO channel D,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Thold improvements
[3]
Reserved
[2:0]
LVDS input skew control for RXO channel E,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Thold improvements
25d/19h
R/W
None
[7]
Reserved
0000_0000
[6:4]
LVDS input skew control for RXO channel A,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Thold improvements
[3]
Reserved
[2:0]
LVDS input skew control for RXE channel A,
000 (default) applies to no delay added, ONE buffer
delay per step adjustment towards Thold improvements
